4-1
AKHEMT-ID
0605-002
1. Description of Recognition Error ID (Example)
1. Description of Recognition Error ID (Example)
[1] [2] [3]
Table 4D1
Recognition Error ID Description of Recognition Error, Cause, and Remedy
0 5 0 ** 001 Component was not found
(Cause 1) Check if the feeder is loaded with components other than the
specifi ed ones (the components to be used).
(Cause 2) The vacuum suction force is too weak.
(Cause 3) An improper nozzle is selected for the components or vice
versa.
(Remedy 1) Check if proper components are used.
(Remedy 2) Check the vacuum pressure.
(Remedy 3) Check the parameters in the nozzle type data and the
component library data.
0 5 1 ** 001 Component was not detected.
(Cause) Component Recognition Error
(Remedy) Contact our service personnel for details.
(Continued to the next page.)
[4]
[1] Recognition Error ID
The recognition error IDs (IDs displayed in the "ERROR" window) are
described in the numerical order.
[2] Description of Recognition Error
Described are the contents of a recognition error that will be displayed
in the "ERROR" window.
[3] Cause and Remedy
Described are the causes and remedial procedures of the error in "[2]
Description of Recognition Error".
The causes and remedies are correlated as follows.
(Cause 1)
→
(Remedy 1)
(Cause 2)
→
(Remedy 2)
(Cause 3)
→
(Remedy 3)
[4] Continued to the next page
This indicates that the related contents are described subsequently on
the next page.
4-2
AKHEMT-ID
2. Recognition Error IDs and Controlled Areas
Basic System of Recognition Error IDs
An error ID is expressed by 8 digits (hexadecimal) as follows.
Z
A
B CC DDD
Detailed Classifi cation
Small Classifi cation
Middle Classifi cation
Large Classifi cation: Classifi cation based on individual
recognition functions
Classifi cation Criteria: Distinction between Recognition
System and Ordinary Errors
Classifi cation Criteria
Table 4D2
Classifi cation Criteria Classifi cation of Recognition Functions
0 Ordinary Errors
1 Recognition System Errors
Large Classifi cation
Table 4D3
Classifi cation Criteria Classifi cation of Recognition Functions
0 Recognition Internal Errors
1 Recognition Communication Errors
(Internal Processing)
2 Recognition Communication Errors
5 Component Recognition Errors
6 PEC Recognition Errors
7 Nozzle Recognition Errors
A Teaching Errors (Reserved)
0602-001
2. Recognition Error IDs and Controlled Areas
4-3
AKHEMT-ID
3. Recognition Error IDs and Remedial Procedures
3.1 Recognition Internal Errors
Z
A
B CC DDD
Detailed Classifi cation: Detailed Classifi cation
Small Classifi cation: Small Classifi cation
Middle Classifi cation: Middle Classifi cation (1)
1: Error in Recognition internal
2: Error in Recognition internal
3: Error in Recognition internal
4: Error in Recognition internal
Large Classifi cation (0)
Classifi cation Criteria
Notice
Recognition Internal Error !
In normal cases, this is not issued outside.
Table 4D4
Recognition Error ID Description of Recognition Error, Cause, and Remedy
0 0 1 00 001 Error in Recognition internal
0 0 1 00 002 Error in Recognition internal
0 0 1 0 0 * ** Error in Recognition internal
0 0 2 0 0 *** Error in Recognition internal
0 0 3 0 0 * ** Error in Recognition internal
0 0 4 0 0 ** * Error in Recognition internal
1 0 * * * * * * Error in Recognition internal
(Cause) Recognition Internal Error
(Remedy) Contact our service personnel for details.
0602-001
3. Recognition Error IDs and Remedial Procedures
