4-22 AKHEMT -ID 3.6 Nozzle Recognition Errors Z A B CC DDD Detailed Classi fi cation: Detailed Classi fi cation Small Classi fi cation: Small Classi fi cation Middle Classi fi cation 0: Nozzle Recognition (Nozzle Missing) 1: …
4-21
AKHEMT-ID
Recognition Error ID Description of Recognition Error, Cause, and Remedy
0 6 E ** 001 Others
(Cause) Self-Diagnostics Error Message
(Remedy) Contact our service personnel for details.
1 6 * * * * * * Others
(Cause) Self-Diagnostics Error Message
(Remedy) Contact our service personnel for details.
0602-001
3.5 PEC Recognition Errors
4-22
AKHEMT-ID
3.6 Nozzle Recognition Errors
Z
A
B CC DDD
Detailed Classifi cation: Detailed Classifi cation
Small Classifi cation: Small Classifi cation
Middle Classifi cation
0: Nozzle Recognition (Nozzle Missing)
1: Nozzle Recognition (Coarse Recognition Error)
2: Nozzle Recognition (Coarse Recognition Error)
3: Nozzle Recognition (Detailed Recognition Error)
8: Nozzle Recognition (Inspection Error)
9: Nozzle Recognition (Judgement Error)
E: Nozzle Recognition (Other Errors)
Large Classifi cation (7)
Classifi cation Criteria
Notice
When an error ID other than the described ones is issued, contact
our service personnel for some advice.
Table 4D9
Recognition Error ID Description of Recognition Error, Cause, and Remedy
0 7 0 ** 001 Nozzle not detected.
0 7 1 ** 001 Nozzle not detected.
0 7 2 ** 001 Nozzle not detected.
0 7 2 ** 002 Nozzle not detected.
0 7 3 ** 101 Edge not detected.
0 7 3 ** 102 Nozzle not detected.
(Cause 1) Abnormal Nozzle Attachment
(Cause 2) The nozzle type data is abnormal.
(Remedy 1) Attach the correct nozzle.
(Remedy 2) Check the nozzle type data. If necessary, correct it.
0 7 8 ** 101 Nozzle size has exceeded the allowable range.
0 7 8 ** 102 Nozzle size has exceeded the allowable range.
0 7 8 ** 201 Check error
0 7 8 ** 202 Check error
(Cause 1) The attached nozzle is different from the nozzle specifi ed in the
placement head/nozzle data.
(Cause 2) The nozzle type data is abnormal.
(Remedy 1) Attach the correct nozzle.
(Remedy 2) Check the nozzle type data. If necessary, correct it.
0602-001
3.6 Nozzle Recognition Errors
4-23
AKHEMT-ID
Recognition Error ID Description of Recognition Error, Cause, and Remedy
0 7 8 ** 301 Nozzle position has exceeded the allowable range.
0 7 8 ** 302 Nozzle position has exceeded the allowable range.
0 7 8 ** 303 Nozzle position has exceeded the allowable range.
0 7 8 ** 304 Nozzle position has exceeded the allowable range.
(Cause) Self-Diagnostics Error Message
(Remedy) Contact our service personnel for details.
0 7 9 * * * * * Others
(Cause) Self-Diagnostics Error Message
(Remedy) Contact our service personnel for details.
0 7 E ** 001 Others
(Cause) Self-Diagnostics Error Message
(Remedy) Contact our service personnel for details.
1 7 * * * * * * Others
(Cause) Self-Diagnostics Error Message
(Remedy) Contact our service personnel for details.
0602-001
3.6 Nozzle Recognition Errors
