3-22
AKHEMT-ID
3.7 Automatic Setup
Table 4C9
Erroe ID Error Name, Description, Cause, and Remedy
490603 Conveyor Width Automatic Adjustment
A PCB exists on the L conveyor.
-----
490604 Conveyor Width Automatic Adjustment
A PCB exists on the R conveyor.
-----
490605 Conveyor Width Automatic Adjustment
A PCB exists on the R conveyor.
-----
490617 Conveyor Width Automatic Adjustment
Software limit
-----
490618 Conveyor Width Automatic Adjustment
There is a PCB on the conveyor.
-----
490619 Conveyor Width Automatic Adjustment
Failed in Program Change Operation (Data Error).
-----
49061a Conveyor Width Automatic Adjustment
Failed in Program Change Operation (Time out).
-----
49061b Conveyor Width Automatic Adjustment
Backup Base zeroing Error.
-----
49061c Conveyor Width Automatic Adjustment
Head Up/Down Axis Zeroing Error.
-----
49061d Conveyor Width Automatic Adjustment
The PCB was detected on the Input conveyor.
Please remove the PCB on an Input conveyor.
49061e Conveyor Width Automatic Adjustment
The PCB was detected on the Cnvr. Positioning 1.
Please remove the PCB on a Cnvr. Positioning 1.
490621 Conveyor Width Automatic Adjustment
The PCB was detected on the Output conveyor.
Please remove the PCB on an Output conveyor.
490690 Conveyor Width Automatic Adjustment
Auto Setup Error (Others).
-----
0609-002
3.7 Automatic Setup
3-23
AKHEMT-ID
Erroe ID Error Name, Description, Cause, and Remedy
490701 Nozzle set up
Nozzle Stocker is not set.
Please check whether it is correctly set to the stocker base.
490702 Nozzle set up
Motor Error Detection.
-----
490703 Nozzle set up
Nozzle Stocker Shutter open/close failed.
There is no fl oat going up of a nozzle, or please check whether there is any
connection etc. in opening and closing.
490704 Nozzle set up
Nozzle Stocker up/dowon failed.
There is no fl oat going up of a nozzle, or please check whether there is any
connection etc. in opening and closing.
490705 Nozzle set up
Nozzle existence confi rmation has error.
Please check whether there is any difference in stocker arrangement data and real
arrangement.
490706 Nozzle set up
Head nozzle existence confi rmation has error.
Please check whether there is any difference in head arrangement data and real
arrangement.
490707 Nozzle set up
There is no free space for nozzle storing.
Please confi rm the Stocker arrangement data.
490708 Nozzle set up
There are neither a free space nor a nozzle for nozzle exchange.
Please set up an insuffi cient nozzle in Noz stocker.
490709 Nozzle set up
Nozzle exchange abnormal data was found.
Please confi rm the nozzle arrangement and the Stocker arrangement data.
49070a Nozzle set up
Nozzle stocker position teaching failed.
Please teach the Noz stocker position again on the instruction screen.
49070b Nozzle set up
Placement Hd / Noz data is not corresponding to the real arrangement.
Please confi rm the real arrangement of the head nozzle arrangement data and the
head.
49070c Nozzle set up
Nozzle level teach error Detection.
Please execute the nozzle level teaching again on the nozzle level teach screen,
and confi rm there is no unexpected value.
49070d Nozzle set up
The nozzle receipt check went wrong.
Please select a recognition image and choose the existence of a nozzle.
0602-001
3.7 Automatic Setup
3-24
AKHEMT-ID
Erroe ID Error Name, Description, Cause, and Remedy
49070e Nozzle set up
The remains nozzle was detected on the head. The nozzle cannot be set to this
position.
Please confi rm the nozzle has not adhered to the position. Moreover, please clean
the line sensor when not adhering.
49070f Nozzle set up
The placed nozzle was undetectable on the head.
Please confi rm whether the nozzle has adhered to the position.
490710 Nozzle set up
The receipt nozzle was undetectable on the head.
Please confi rm whether the nozzle has adhered to the position.
490711 Nozzle set up
The remains nozzle was detected on the head.
Please confi rm the nozzle has not adhered to the position. Moreover, please clean
the line sensor when not adhering.
490712 Nozzle set up
The linear measure error occurred in the head nozzle existence check.
Please confi rm the nozzle arrangement, and execute the level teaching.
490713 Nozzle set up
The nozzle exchange sequence error occurred.
Please confi rm the nozzle arrangement.
490714 Nozzle set up
The nozzle placement in nozzle stocker is different from the nozzle data.
Please confi rm the nozzle placement.
490715 Nozzle set up
It failed in nozzle ID detection.
Please confi rm the nozzle ID.
490716 Nozzle set up
Time-out of close nozzle stocker operation.
Nozzle stocker was opened for safety. Please confi rm whether there is no rise to the
surface and the nozzle is not in opening and shutting caught state.
0602-001
3.7 Automatic Setup
