3-27
AKHEMT-ID
Erroe ID Error Name, Description, Cause, and Remedy
4b0406 Recycling Conveyor
Component trash Box (front) was fi lled
Please open the safety door, and empty the comp abandonment box.
4b0501 Manual Opn Error
Operation was not completed within predetermined time.
-----
4b050f Manual Opn Error
Error was detected during operation.
-----
4b0601 Auto Run Start Error
Production operation has not started within predetermined time. (Please push a
start button again)
-----
4b0701 Communication Timeout
Communication failed to STG. #1 CPU
-----
4b0703 Communication Timeout
Communication failed to Recog. CPU
-----
4b0704 Communication Timeout
Communication failed to STG CPU
-----
4b0801 Linear measure operation is abnormal.
Linear measure was found abnormality while measuring.
-----
4b0901 Firmware Updating Timeout
Firmware update did not end in prescribed time.
-----
4b0a01 Feeder Alarm
Feeder Alarm. Please confi rm the feeder and the component.
-----
4b0b01 Feeder base-main body connector unconnection
Feeder base-main body connector has get out of joint.
Please connect the connector of the feeder base with the main body, and push
stage preparation completion SW.
0605-002
3.9 Others
3-27-1
AKHEMT-ID
Erroe ID Error Name, Description, Cause, and Remedy
4b0c01 Nozzle Confi rmation Error before pick up comp
Abandonment is stopped because comp. had been detected on the nozzle.
Please confi rm and clean up the nozzle when this error continues.
4b0c02 Nozzle Confi rmation Error before pick up comp
Residual components were found in the nozzle while production operation.
Please confi rm whether there is an error in the PCB.
4b0c03 Nozzle Confi rmation Error before pick up comp
Abandonment is stopped because comp. had been detected on the nozzle.
Please confi rm and clean up the nozzle when this error continues.
4b0d01 Serial Out Mode Error
There was no response to the Serial Out Mode.
-----
4b0d02 Serial Out Mode Error
Communication failed to Shtg. of Comp. Host.
-----
4b0d03 Serial Out Mode Error
Communication with the Shtg. of Comp. Host has error.
-----
4b0e01 Splicing tape set error
The joint part of splicing tape is not correctly set.
Please extract a feeder and check whether the tape has separated from the guide.
-----
4b0f01 Decreasing of Comp. Hdlg. Rate
It stopped automatically by the rate fall of feeder adsorption.
-----
4b0f02 Decreasing of Comp. Hdlg. Rate
It stopped automatically by the rate fall of nozzle adsorption.
-----
0605-001
3.9 Others
3-28
AKHEMT-ID
3.10 Pickup Error
Table 4C12
Erroe ID Error Name, Description, Cause, and Remedy
500101 Comp. Missing (Sensor)
There is a possibility that the picked comps. have fallen on the feeder and please
confi rm it.
500102 Comp. Missing (Sensor)
There is a possibility that the picked comps. have fallen on the feeder and please
confi rm it.
500201 Vacuum Sensor Error
-----
500301 Comp. Missing (Recog)
There is a possibility that the picked comps. have fallen on the feeder and please
confi rm it.
500401 Comp. Recog Error
-----
500501 Shortage of Component
Shortage of Component
-----
500502 Feeder Reload Stop
Feeder Reload Stop (Splicing)
-----
500601 V.Bend Detection Error
-----
500701 Shortage of Component (Alternated Feeder)
-----
500a01 Auto Recovery Pause
Attach the new comp. And press [READY]. Then, press [START] button to re-start.
-----
500a02 Auto Recovery Pause
Quick recovery stop
-----
500c01 Comp. Vertical (Sensor)
-----
0609-002
3.10 Pickup Error
