4-16
AKHEMT-ID
Recognition Error ID Description of Recognition Error, Cause, and Remedy
0 5 1 ** 601 Shape (L type) cannot be detected
0 5 1 ** 602 Shape (U type) cannot be detected.
0 5 1 ** 603 Shape (edge) cannot be detected.
0 5 1 ** 604 Shape (rectangle) cannot be detected.
0 5 1 ** 605 Shape (oval) cannot be detected.
(Cause) Component Recognition Error
(Remedy) Contact our service personnel for details.
0 5 2 ** 101 More than two corners of a component are hidden by the protruded nozzle.
0 5 2 ** 102 Corner not detected.
0 5 2 ** 201 Some edges cannot be detected because they are hidden by the nozzle.
0 5 2 ** 202 Edge not detected.
0 5 2 ** 203 Some edges cannot be detected because they are hidden by the nozzle.
0 5 2 ** 204 Edge not detected.
0 5 2 ** 301 Angle calculation impossible.
(Cause) Component Recognition Error
(Remedy) Contact our service personnel for details.
0 5 2 ** 401 Impossible to set the window for lead detection.
0 5 2 ** 402 The length position of a lead can't be set up.
0 5 2 ** 403 The detected number of leads is smaller than the set value.
0 5 2 ** 404 The detected number of leads is larger than the set value.
(Cause) The results of the lead inspection differ from the parameters
specifi ed in the component library data for the selected
components.
(Remedy) Check the leads of the selected component and the component
library data.
Correct wrong parameters if they are set in the component
library data.
0 5 2 ** 501 Electrode(ball) which is in agreement with data was undetectable.
0 5 2 ** 502
Since a suffi cient number of Electrode(ball) were undetectable, it cannot
position.
(Cause) Component Recognition Error
(Remedy) Contact our service personnel for details.
0 5 2 ** 601 Shape (L type) cannot be detected.
0 5 2 ** 602 Shape (U type) cannot be detected.
0 5 2 ** 603 Shape (edge) cannot be detected.
0 5 2 ** 604 Shape (rectangle) cannot be detected.
0 5 2 ** 605 Shape (oval) cannot be detected.
0 5 2 ** 606 There is shape that cannot be detected as in the shade of nozzle etc.
0 5 2 ** 607 The Shape corresponding to data was not able to be detected.
(Cause) Component Recognition Error
(Remedy) Contact our service personnel for details.
0602-001
3.4 Component Recognition Errors
4-17
AKHEMT-ID
Recognition Error ID Description of Recognition Error, Cause, and Remedy
0 5 8 ** 001 The pick-up position has deviated greatly.
0 5 8 ** 002 The pick-up position has deviated greatly in X direction.
0 5 8 ** 003 The pick-up position has deviated greatly in Y direction.
0 5 8 ** 004 The pick angular skew is big.
(Cause) Component Recognition Error
(Remedy) Contact our service personnel for details.
0 5 8 ** 101 Component outward length X is incorrect.
0 5 8 ** 102 Component outward length X is shorter than the tolerance.
0 5 8 ** 103 Component outward length X is longer than the tolerance.
0 5 8 ** 104 Component outward length Y is incorrect.
0 5 8 ** 105 Component outward length Y is shorter than the tolerance.
0 5 8 ** 106 Component outward length Y is longer than the tolerance.
0 5 8 ** 107 Component outward length X or Y is incorrect.
0 5 8 ** 108 Component outward length X or Y is shorter than the tolerance.
0 5 8 ** 109 Component outward length X or Y is longer than the tolerance.
(Cause 1) Wrong parameters are set in the "X [mm]" and "Y [mm]" text
boxes of "Mold size" and the "Mold size tolerance X [mm]"
and "Mold size tolerance Y [mm]" text boxes for the selected
components.
X
Y
Fig. 4D1
(Remedy 1) Check the selected components and the parameters set in the
"X [mm]" and "Y [mm]" text boxes of "Mold size" and the "Mold
size tolerance X [mm]" and "Mold size tolerance Y [mm]" text
boxes for the selected components in the component library
data.
Correct wrong parameters if they are set in the component
library data.
0602-001
3.4 Component Recognition Errors
4-18
AKHEMT-ID
Recognition Error ID Description of Recognition Error, Cause, and Remedy
0 5 8 ** 201 The number of leads is small.
0 5 8 ** 202 The number of leads is large.
0 5 8 ** 203 The lead width is shorter than the tolerance.
0 5 8 ** 204 The lead width is longer than the tolerance.
0 5 8 ** 205 Gap of the width direction of a lead is larger than a permissible value.
0 5 8 ** 206 Gap of the length direction of a lead is larger than a permissible value.
0 5 8 ** 207 The detected lead length direction positions differ greatly.
(Cause) The results of the lead inspection differ from the parameters
specifi ed in the component library data for the selected
components.
(Remedy) Check the leads of the selected component and the component
library data.
Correct wrong parameters if they are set in the component
library data.
0 5 8 ** 301 Electrode(ball) length is incorrect.
0 5 8 ** 302 Electrode(ball) position is larger than a permissible value.
0 5 8 ** 401 A shape positional gap is larger than a permissible value.
(Cause) Component Recognition Error
(Remedy) Contact our service personnel for details.
0 5 9 ** 101 Error in Polarity Detection.
0 5 9 ** 201 The component is reversed.
0 5 9 ** 301 There is the electrode (lead) that must not exist
0 5 9 ** 302 There is the electrode (ball) that must not exist
0 5 9 ** 303 There is the shape that must not exist.
(Cause) Component Recognition Error
(Remedy) Contact our service personnel for details.
0 5 A ** 101 The pick-up position has deviated greatly in X direction.
0 5 A ** 102 The pick-up position has deviated greatly in Y direction.
0 5 A ** 103 The pick angular skew is big.
(Cause) Component Recognition Error
(Remedy) Contact our service personnel for details.
0 5 E ** 001 Others
0 5 E ** 002 Others
0 5 E ** 003 Others
0 5 E ** 004 Others
0 5 E ** 005 Others
0 5 E ** 006 Others
0 5 E ** 007 Others
0 5 E ** 008 Others
(Cause) Component Recognition Error
(Remedy) Contact our service personnel for details.
1 5 * * * * * * Others
(Cause) Self-Diagnostics Error Message.
(Remedy) Contact our service personnel for details.
0602-001
