3.12 Automatic Teaching
Table 4C14
Erroe ID Error Name, Description, Cause, and Remedy
600101 PCB recog camera & beam offset teach.
-----
600102 PCB recog camera & beam offset teach.
-----
600103 PCB recog camera & beam offset teach.
-----
600104 PCB recog camera & beam offset teach.
-----
600105 PCB recog camera & beam offset teach.
-----
600106 PCB recog camera & beam offset teach.
-----
600107 PCB recog camera & beam offset teach.
-----
600108 PCB recog camera & beam offset teach.
-----
600109 PCB recog camera & beam offset teach.
-----
600201 Comp. Recog. Camera offset teach.
The glass Jig can not able to be recognized.
-----
600202 Comp. Recog. Camera offset teach.
It entered in a specifi ed frequency or less and it did not enter a permissible value.
-----
600301 Head Rotate Theta Axis offset
-----
600401 Head Rotate center offset teach
-----
600501 Reference mark position teach
-----
0602-001
3.12 Automatic Teaching
3-33
AKHEMT-ID
Erroe ID Error Name, Description, Cause, and Remedy
600601 Nozzle position offset teach
-----
600701 Fly recog. Offset teach
-----
600801 Feeder offset (A) teach
Please push the Feeder Ready SW
-----
600802 Feeder offset (A) teach
Feeder recog Mark Error
Manual Alignment
600803 Feeder offset (A) teach
Feeder connection is set in test mode.
-----
600804 Feeder offset (A) teach
-----
600805 Feeder offset (A) teach
Feeder recog. Process time over
-----
600901 Feeder offset (B) teach
-----
601000 Master nozzle level offset teach
-----
601101 Nozzle level offset teach
The nozzle level instruction result exceeded the tolerance.
-----
601200 Y Axis offset teach
-----
601301 Nozzle stocker offset teaching
Stocker Mark #1 Recognition Error
Please select Mnl Align Mark1 and adjust the manual.
601302 Nozzle stocker offset teaching
Stocker Mark #2 Recognition Error
Please select Mnl Align Mark2 and adjust the manual.
601400 Master nozzle level offset teach
-----
0602-001
3.12 Automatic Teaching
3-34
AKHEMT-ID
Erroe ID Error Name, Description, Cause, and Remedy
601501 Recog camera light teach
Recog Process error
-----
601601 Comp. Recog. Camera magnifi cation teach.
Recog Process error
-----
601a01 Linear measure correction re-teach
The linear measure reading is abnormal.
Please confi rm whether the nozzle has adhered to the position.
601b01 Automatic teaching
The nozzle is not installed.
Please install the nozzle.
