4-25 AKHEMT -ID 3.8 V arious T each Errors Z A B CC DDD Detailed Classi fi cation: Detailed Classi fi cation Small Classi fi cation: Small Classi fi cation Middle Classi fi cation: Middle Classi fi cation 0: Character Recognit…
4-24
AKHEMT-ID
3.7 Character Recognition Errors
Z
A
B CC DDD
Detailed Classifi cation: Detailed Classifi cation
Small Classifi cation: Small Classifi cation
Middle Classifi cation
0: Character Recognition (Nozzle Missing)
1: Character Recognition (Coarse Recognition Error)
2: Character Recognition (Detailed Recognition Error)
8: Character Recognition (Inspection Error)
9: Character Recognition (Judgement Error)
E: Character Recognition (Other Errors)
Large Classifi cation (8)
Classifi cation Criteria
Notice
When an error ID other than the described ones is issued, contact
our service personnel for some advice.
Table 4D10
Recognition Error ID Description of Recognition Error, Cause, and Remedy
0 8 0 ** 001 The nozzle is not stored.
(Cause) The nozzle is not stored.
(Remedy) Store the nozzle.
0 8 1 ** 001 The locator mark cannot be detected.
0 8 2 ** 001 There are characters that cannot be detected.
(Cause 1) The direction of the nozzle attachment is wrong.
(Cause 2) The diffusion plate is dirty.
(Remedy 1) Attach the nozzle in the correct direction.
(Remedy 2) Clean the diffusion plate.
0 8 E ** 001 Others.
(Cause) Self-Diagnostics Error Message.
(Remedy) Contact our service personnel for details.
1 8 * ** * ** Others.
(Cause) Self-Diagnostics Error Message.
(Remedy) Contact our service personnel for details.
0602-001
3.7 Character Recognition Errors
4-25
AKHEMT-ID
3.8 Various Teach Errors
Z
A
B CC DDD
Detailed Classifi cation: Detailed Classifi cation
Small Classifi cation: Small Classifi cation
Middle Classifi cation: Middle Classifi cation
0: Character Recognition (Nozzle Missing)
E: Character Recognition (Other Errors)
Large Classifi cation (A)
Classifi cation Criteria
Notice
When an error ID other than the described ones is issued, contact
our service personnel for some advice.
Table 4D11
Recognition Error ID Description of Recognition Error, Cause, and Remedy
0 A 0 ** 001 Lighting teaching Error
0 A 0 ** 002 Lighting teaching Error
0 A 0 ** 003 Lighting teaching Error
0 A 0 ** 004 Lighting teaching Error
(Cause) Lighting Teaching Error
(Remedy) Contact our service personnel for details.
0 A 0 ** 010 The front reverse side of the Jig is opposite.
0 A 0 ** 011
0 A 0 ** 012
(Cause) Improper Jig Attachment
(Remedy) Check how the jig is attached. If necessary, set it up correctly.
0 A 0 ** 013 Lighting teaching Error
0 A 0 ** 020 Lighting teaching Error
(Cause) Lighting Teaching Error
(Remedy) Contact our service personnel for details.
0 A E ** 001 Others
(Cause) Self-Diagnostics Error Message
(Remedy) Contact our service personnel for details.
1 A * * * * * * Others
(Cause) Self-Diagnostics Error Message
(Remedy) Contact our service personnel for details.
0602-001
3.8 Various Teach Errors
4-26
AKHEMT-ID
