3-25
AKHEMT-ID
3.8 Head-Related Errors
Table 4C10
Erroe ID Error Name, Description, Cause, and Remedy
4A0101 Head Zero Return
NL axis zeroing Error. Please confi rm the nozzle has not fallen when you push the
beam by the hand.
When the lock of a safety door cannot be canceled, please push an emergency stop
button. (Please confi rm the nozzle has not fallen when you push the beam by the
hand.) Please check error on a “MAINT-DVC CHK- MOTOR” screen.
4A0102 Head Zero Return
HL axis zeroing Error. Please confi rm the nozzle has not fallen when you push the
beam by the hand.
When the lock of a safety door cannot be canceled, please push an emergency stop
button. (Please confi rm the nozzle has not fallen when you push the beam by the
hand.) Please check error on a “MAINT-DVC CHK- MOTOR” screen.
4A0103 Head Zero Return
L1 axis zeroing Error. Please confi rm the nozzle has not fallen when you push the
beam by the hand.
When the lock of a safety door cannot be canceled, please push an emergency stop
button. (Please confi rm the nozzle has not fallen when you push the beam by the
hand.) Please check error on a “MAINT-DVC CHK- MOTOR” screen.
4A0104 Head Zero Return
L2 axis zeroing Error. Please confi rm the nozzle has not fallen when you push the
beam by the hand.
When the lock of a safety door cannot be canceled, please push an emergency stop
button. (Please confi rm the nozzle has not fallen when you push the beam by the
hand.) Please check error on a “MAINT-DVC CHK- MOTOR” screen.
4A0105 Head Zero Return
L3 axis zeroing Error. Please confi rm the nozzle has not fallen when you push the
beam by the hand.
When the lock of a safety door cannot be canceled, please push an emergency stop
button. (Please confi rm the nozzle has not fallen when you push the beam by the
hand.) Please check error on a “MAINT-DVC CHK- MOTOR” screen.
0609-002
3.8 Head-Related Errors
3-26
AKHEMT-ID
3.9 Others
Table 4C11
Erroe ID Error Name, Description, Cause, and Remedy
4b0101 Head Mis-Pickup Detection
Auto Run can’t be performed with the Mis-Pickup Component on the head.
Please perform abandonment operation from a control menu.
4b0201 Feeder communication Error.
Communication with the feeder has error.
Please check the number of component remain.
4b0202 Feeder communication Error.
Communication with the feeder has error. (System error)
-----
4b0203 Feeder communication Error
Feeder Alarm. Please confi rm the feeder and the component.
-----
4b0301 Feeder Base
The feeder base detection was turned off while the cutter was working.
-----
4b0302 Feeder Base
The feeder unclamp operation was not completed within predetermined time.
-----
4b0303 Feeder Base
Feeder operation errors
Please check after removing feeder in case using tape feeder. Please check part of
supply in case using tray.
4b0304 Feeder Base
The feeder clamp operation was not completed within predetermined time.
-----
4b0401 Recycling Conveyor
The recycling conveyer (back) was fi lled.
Please push a manual switch, and remove parts on the recycling conveyer.
4b0402 Recycling Conveyor
The recycling conveyer (front) was fi lled.
Please push a manual switch, and remove parts on the recycling conveyer.
4b0403 Recycling Conveyor
The recycling conveyer (back) motor operation time out.
There is a possibility a problem in the motor wiring. Please check the motor wiring.
Please begin the production.
4b0404 Recycling Conveyor
The recycling conveyor (front) motor operation time out.
There is a possibility a problem in the motor wiring. Please check the motor wiring.
Please begin the production.
4b0405 Recycling Conveyor
Component trash Box (back) was fi lled.
Please open the safety door, and empty the comp abandonment box.
0609-003
3.9 Others
3-27
AKHEMT-ID
Erroe ID Error Name, Description, Cause, and Remedy
4b0406 Recycling Conveyor
Component trash Box (front) was fi lled
Please open the safety door, and empty the comp abandonment box.
4b0501 Manual Opn Error
Operation was not completed within predetermined time.
-----
4b050f Manual Opn Error
Error was detected during operation.
-----
4b0601 Auto Run Start Error
Production operation has not started within predetermined time. (Please push a
start button again)
-----
4b0701 Communication Timeout
Communication failed to STG. #1 CPU
-----
4b0703 Communication Timeout
Communication failed to Recog. CPU
-----
4b0704 Communication Timeout
Communication failed to STG CPU
-----
4b0801 Linear measure operation is abnormal.
Linear measure was found abnormality while measuring.
-----
4b0901 Firmware Updating Timeout
Firmware update did not end in prescribed time.
-----
4b0a01 Feeder Alarm
Feeder Alarm. Please confi rm the feeder and the component.
-----
4b0b01 Feeder base-main body connector unconnection
Feeder base-main body connector has get out of joint.
Please connect the connector of the feeder base with the main body, and push
stage preparation completion SW.
0605-002
