7.6 Maintenance Component List
Listed below are the parts for which maintenance work is required in several
years. The list below is provided for your reference.
If the recommended years of the component has passed or the component is
damaged, replace it.
GT-38080 and GD-38080 Maintenance Component List
Table G5A
Component Name PART No. PART NAME Q'ty
Recommended
Years
Worm Wheel ASSY (L) KYD-MC112-00 ASSY_GEAR(L) 1 3 years / 30 million feeds
Worm Wheel ASSY (R) KYD-MC113-00 ASSY_GEAR(R) 1 3 years / 30 million feeds
Take-up Worm Wheel KYD-MC131-00 GERA(HASUBA) 2 3 years / 20 million feeds
Take-up Worm Motor KYD-MC11S-00 MOTOR_DC 2 3 years / 16 million feeds
Timing Belt KYD-MC13V-00 BELT_TIMING 2 4 years / 40 million feeds
Take-up Gear (Flat End Wheel 1) KYD-MC130-00 GEAR(HIRA-1) 2 4 years / 20 million feeds
Take-up Gear (Flat End Wheel 2) KYD-MC12L-00 ASSY_GEAR 2 4 years / 20 million feeds
Sprocket ASSY (L) KYD-MC12G-00 ASSY_SPROCKET_L 1 -
Sprocket ASSY (R) KYD-MC12H-00 ASSY_SPROCKET_R 1 -
Cover (LA) KYD-MC10H-00 COVER(LA) 1 -
Cover (LB) KYD-MC10K-00 COVER (LB) 1 -
Cover (RB) KYD-MC10L-00 COVER (RB) 1 -
Cover (KIBAN) KYD-MC10J-00 COVER (KIBAN) 1 -
Front End Guide KYD-MC13H-00 GUIDE 1 -
Front Hook KYD-MC10T-00 ASSY_HOOK 2 -
Front Hook Spring KYD-MC12P-00 SPRING_COMP(F) 2 -
Suppressor ASSY (GT-38080) KYD-MC12M-00 ASSY_LEVER (GT-38080) 2 -
Suppressor Lock Spring KYD-MC12A-00 SPRING_COMP(SUP) 2 -
Magnetic Plate KYD-MC115-00
ASSY_PLATE (MAG)
2 -
Tension Lever ASSY (L) KYD-MC12J-00
ASSY_TENSION(L)
1 -
Tension Lever ASSY (R) KYD-MC12K-00
ASSY_TENSION(R)
1 -
Roll-in Preventive Plate KYD-MC11X-00
COVER
2 -
Scraper (L) KYD-MC13F-00
BLOCK(L)
1 -
Scraper (R) KYD-MC13G-00
BLOCK(R)
1 -
Take-up Cancel Lever (L) KYD-MC118-00
ASSY_LEVER(L)
1 -
Take-up Cancel Lever (R) KYD-MC119-00
ASSY_LEVER(R)
1 -
Conductive Grip Lever KYD-MC125-00 ASSY_GRIP 1 -
Conductive Grip Cover KYD-MC11W-00 COVER(GRIP) 1 -
Operation Panel KYD-MC121-00 PCB_MOUNT 1 -
Cover Tape Outlet Cover KYD-MC12N-00 COVER(FUTA) 1 -
Cutter KYD-MC13X-00 CUTTER 1 -
Note
(a) The numbers entitled "Recommended Years" indicate the referential values
with 4 mm feed pitch.
Replacement may be required depending on the *actual use or maintenance
status regardless of the recommended years or specied feed amount.
*When picking up components continuously with one feeder
(b) Because the cutter blade is very sharp, when the cutter is to be changed, do
not hold the blade section. Take the greatest care not to get injured.
1901-005
7.6 Maintenance Component List
OM-1743
7-30
GD-38083 Maintenance Component List
Table G7A
Component Name PART No. PART NAME Q'ty
Recommended
Years
Worm Wheel ASSY (L) KYD-MC112-00 ASSY,GEAR (L) 1 3 years / 30 million feeds
Worm Wheel ASSY (R) KYD-MC113-00 ASSY,GEAR (R) 1 3 years / 30 million feeds
Take-up Worm Wheel KYD-MC131-00 GEAR(HASUBA) 2 3 years / 20 million feeds
Take-up Worm Motor KYD-MC11S-00 MOTOR_DC 2 3 years / 16 million feeds
Timing Belt KYD-MC13V-00 BELT_TIMING 2 4 years / 40 million feeds
Take-up Gear (Flat End Wheel 1) KYD-MC130-00 GEAR(HIRA-1) 2 4 years / 20 million feeds
Take-up Gear (Flat End Wheel 2) KYD-MC12L-00 GEAR(HIRA-2) 2 4 years / 20 million feeds
Sprocket ASSY (L) KYD-MC12G-00 ASSY_SPROCKET (L) 1 -
Sprocket ASSY (R) KYD-MC12H-00 ASSY_SPROCKET (R) 1 -
Cover (LA) KYD-MC10H-00 COVER (LA) 1 -
Cover (LB) KYD-MC10K-00 COVER (LB) 1 -
Cover (RB) KYD-MC10L-00 COVER (RB) 1 -
Cover (KIBAN) KYD-MC10J-00 COVER (KIBAN) 1 -
Front End Guide KYD-MC13H-00 GUIDE 1 -
Front Hook KYD-MC10T-00 ASSY_HOOK 2 -
Front Hook Spring KYD-MC12P-00 SPRING_COMP(F) 2 -
Suppressor ASSY (GD-38083) KYD-MC10S-00 ASSY_LEVER (GD-38083) 2 -
Suppressor Lock Spring KYD-MC12A-00 SPRING_COMP(SUP) 2 -
Magnetic Plate KYD-MC114-00
ASSY_PLATE (MAG)
2 -
Tension Lever ASSY (L) KYD-MC12J-00
ASSY_TENSION(L)
1 -
Tension Lever ASSY (R) KYD-MC12K-00
ASSY_TENSION(R)
1 -
Roll-in Preventive Plate KYD-MC11X-00
COVER
2 -
Scraper (L) KYD-MC13F-00
BLOCK(L)
1 -
Scraper (R) KYD-MC13G-00
BLOCK(R)
1 -
Take-up Cancel Lever (L) KYD-MC118-00
ASSY_LEVER(L)
1 -
Take-up Cancel Lever (R) KYD-MC119-00
ASSY_LEVER(R)
1 -
Conductive Grip KYD-MC125-00 ASSY_GRIP 1 -
Conductive Grip Cover KYD-MC11W-00 COVER(GRIP) 1 -
Operation Panel KYD-MC121-00 PCB_MOUNT 1 -
Cover Tape Outlet Cover KYD-MC12N-00 COVER(FUTA) 1 -
Cutter KYD-MC13X-00 CUTTER 1 -
Note
(a) The numbers entitled "Recommended Years" indicate the referential values
with 4 mm feed pitch.
Replacement may be required depending on the *actual use or maintenance
status regardless of the recommended years or specied feed amount.
*When picking up components continuously with one feeder
(b) Because the cutter blade is very sharp, when the cutter is to be changed, do
not hold the blade section. Take the greatest care not to get injured.
1901-005
7.6 Maintenance Component List
OM-1743
7-31
8. Specications of Tape Feeders
8.1 Specications of 8 mm Dual Tape Feeder
Table H1
Model
Tape
Width
×
Feed
Pitch
(mm)
Types of
Tape
Standard
Set
Reel
Outer
Diameter
×
Width
(mm)
Chute
Height
(mm)
Referential
Components
Remarks
GT-38080
GD-38080
8×2
Paper
φ
178 to
382
×
14.4
104.0
1005
•
Barcode Label Color
: White
8×4
2012
3216
3225
8×2
Embossed
8×4
GD-38083
8×1
Paper
0402
0603
1005
•
Barcode Label Color
: Blue + White
•
Applicable to 1 mm
pitch tape
8×2
8×2 Embossed
Note
The sizes of the components entitled "Referential Components" differ depending
on the component makers.
The components are shown as types for your reference.
1209-001
8. Specications of Tape Feeders
OM-1743
8-1
