1209-001 OM-1743 2-24

1209-001

•

Adjusting Procedure

Procedure

(1) Loosen the hexagon nut.

(2) Turn the groove on the adjusting bolt three times clockwise using a

screwdriver.

(When the bolt is turned around three times from the standard position, the

gap distance between the ange and hexagon nut becomes "1.7 mm" and the

tape take-up strength becomes 1.2 times more of the standard strength.

(3) Return the hexagon nut to the upper surface position and x.

2.7 8 mm Cover Tape Tension Lever Section Spring Setup

OM-1743

2-23

1209-001

OM-1743

2-24

1209-001

3. Tape Feeder Attachment and Detachment

Procedures

Notice

Before setting the tape feeder onto the bank feeder change cart, follow

the instructions below.

•

Lock the caster brake (2 locations) of the bank feeder change cart.

•

If the tape feeder rises, it might cause breakdown to the pick-up nozzle

or machine (SIGMA-F8) or pick-up error.

Set the tape feeder correctly.

•

After the suppressor has been moved up and down, for tape setting

or replacement, make sure that the tape feeder front hook is securely

caught, and that the suppressor does not rise.

With the dual tape feeder, make sure that the suppressor on the other

side does not rise either.

•

Make sure that the cover tape is not caught at the peeling section on

the suppressor.

•

Make sure that the excess tape section is appropriate (5 to 10 mm)

and that the tape end is not folded.

•

Make sure that the cover tape passes correctly onto the roller section

and that it has been inserted into the cover tape housing section.

Also, make sure that there is no sag in the cover tape.

CAUTION

•

When the bank feeder change cart is to be

moved, hold the handle and move it.

•

When the bank feeder change cart is to be

moved, take care that the cart does not hit your

foot.

•

In particular, in the case that the oor is not even

or the cart is caught due to a stage difference or

slacken carpet, the cart movement resistance

might be increased suddenly.

3. Tape Feeder Attachment and Detachment Procedures

OM-1743

3-1
