1209-001 Chip component or foreign substance including debris Remedy : Detach the cover and remove any foreign substance. Cause : Chip component or foreign substances including debris have entered the take-up gear . 1 1.…
11.4 Cover Tape Take-up Action not performed
Remedy
: Correct the cover tape route.
Incorrect cover tape route
If the cover tape route is incorrect, it might cause a take-up error or feed error.
Cause : Incorrect cover tape route on the take-up tension lever section
Notice
Remedy
: Set the cover tape correctly.
Twist
If the cover tape is set incorrectly, it might cause a take-up error or feed error.
Cause : Twisted cover tape has been set.
Notice
1209-001
11.4 Cover Tape Take-up Action not performed
OM-1743
11-6
1209-001
Chip component or foreign
substance including debris
Remedy
: Detach the cover and remove any foreign substance.
Cause : Chip component or foreign substances including debris have entered
the take-up gear.
11.4 Cover Tape Take-up Action not performed
OM-1743
11-7
11.5 Cover Tape cut off
Remedy
: Replace with new tape.
When a tape becomes old, its characteristics are changed, e.g., its tolerance and adhesive strength.
Cause : Old tape is being used
Note
1209-001
Chip component or foreign
substance including debris
Remedy
: Remove any chip component or foreign substance such as debris attached inside the
suppressor and completely clean the suppressor.
If the taping component is mounted with any foreign substance attached, the suppressor
might be deformed or a pick-up error occur.
Therefore, clean it.
Cause : Chip component or foreign substance such as debris has been attached
inside the suppressor and it damages the cover tape.
Notice
11.5 Cover Tape cut off
OM-1743
11-8
