1 1209-001 Before Use W e are grateful to you for purchasing these tape feeders for Y amaha modular mounter (chip mounter). These tape feeders supply chip components to the chip mounter (SIGMA-F8). This instruction manua…

Before using this service manual, please note the following items.

1. The contents of this service manual are subject to change for improvement

without prior notice. Please pay attention to the latest information that will

be provided or issued by our company.

2. The copyright of the service manual belongs to YAMAHA MOTOR CO.,

LTD.

This service manual shall not in any shape or form, in whole or part, be

reproduced, copied or disclosed to any third party without the written

content of the publisher.

3. Our company shall not be held to any liability for any damages suffered

or incurred by the end user, arising from any operations other than those

(including the purposes and methods) described in this service manual.

Be sure to handle the machine carefully.

4. This service manual neither guarantees any license to industrial property

rights, etc., nor grants any license of such rights.

1701-004

OM-1743

11209-001

Before Use

We are grateful to you for purchasing these tape feeders for Yamaha modular mounter

(chip mounter).

These tape feeders supply chip components to the chip mounter (SIGMA-F8).

This instruction manual describes the functions, handling, and operations of these tape

feeders for those who have nished the basic training of the chip mounter.

Before operating these tape feeders, please read this instruction manual carefully to fully

understand the instructions and precautionary measures for safety purposes.

After reading through this manual, please use this manual as an occasional reference and

keep it within reach.

OM-1743

21209-001

About the Instruction Manual

First of all, please read the paragraphs in "Caution and Warning" and "Safety Precautions"

(rst part of this manual).

Identifying Icons in Manual

Notice

This icon shows an important precautionary or a regulatory item.

Note

This icon shows the descriptions for correct operations of the machine.

Reference

This icon shows the items to be referred to.

Procedure

This icon shows the operation procedures.

OM-1743
