OM-1743 Safe-9 1209-001 4. Alert Labels 4. Alert Labels The alert labels (described below) are used for this machine. Please read the instructions on each label carefully and check the contents, observing the actual obje…
OM-1743
Safe-81209-001
3. Alert Indications in Instruction Manual
Alert Indications described as "
CAUTION
" (continued)
Alert Description Pages
•
The cutter blade in the tape cutting jig is very sharp, take the
greatest care not to get injured.
Also, take care not to catch your nger in the spring section.
•
When the tape is to be cut off by using the tape cutting jig, set
the tape on the pilot pins and hold it securely with your thumb
and the forenger; then cut off the tape slowly and carefully so
as not to cut your nger.
•
When the tape cutting jig is not to be used, lock it with the lock
lever while the cutter blade is closed, and keep it in a specied
place.
•
If, because of a chip on the cutter blade in the tape cutting jig, the
tape cannot be cut easily, unusually strong force is required to cut off
the tape, which may cause personal injury.
In such a case, purchase a new tape cutting jig.
6.4
Cut it off with the greatest care so as not to cut your nger. 6.5.1
Only trained persons should perform maintenance, both carefully
and according to the specied procedures.
7.1
Safety Precautions
OM-1743
Safe-91209-001
4. Alert Labels
4. Alert Labels
The alert labels (described below) are used for this machine.
Please read the instructions on each label carefully and check the contents, observing the
actual object.
Be sure to follow the instructions for safety purposes.
These labels should be kept clean and easily legible at a far safe distance.
In the case that the warning label is degraded and cannot be read, contact the Marketing
Dept., or sales agent of Yamaha Motor Co., Ltd. to replace it by new one.
Location of Alert Labels
The alert labels are afxed on dangerous and caution-required areas.
Refer to "Alert Labels and Description" for details.
Fig. X1
Safety Precautions
OM-1743
Safe-10
Alert Labels and Description
No. Alert Labels and Description
(1)
Description
In this tape feeder, a permanent magnet is used in the tape feed section and the
cover tape take-up section.
Nobody with an implanted pacemaker should operate the tape feeder.
Their pacemaker might be affected by magnetism, which might cause a serious
accident.
(2)
Description
If the tape feeder is dropped, it might injure your foot or the feeder itself be
damaged.
Handle one by one carefully and take care not to drop.
WARNING
CAUTION
1209-001
4. Alert Labels
Safety Precautions
