1209-001 1 1.3 T ape Feed not correctly performed Remedy : Remove any chip component or foreign substance such as debris attached onto the suppressor and completely clean the suppressor . Notice If the taping component i…
1209-001
11.2 Tape Feeder not correctly locked
Remedy
: Remove any chip component or foreign substance such as debris attached on the
feeder base and completely clean the feeder base.
If the tape feeder is used while it has not been locked, it might cause damage to the machine or pick-
up error.
Attach the tape feeder securely to the feeder base.
Cause : Chip component or foreign substances including debris have been
attached onto the feeder base.
Note
11.2 Tape Feeder not correctly locked
OM-1743
11-3
1209-001
11.3 Tape Feed not correctly performed
Remedy
: Remove any chip component or foreign substance such as debris attached onto the
suppressor and completely clean the suppressor.
Notice
If the taping component is mounted with any foreign substance attached, the suppressor
might be deformed or a pick-up error occur.
Therefore, clean it.
Cause : Chip component or foreign substances including debris have been
attached inside the suppressor and the suppressor does not securely
hold the tape.
Remedy
: Engage the carrier tape sprocket hole with the sprocket teeth.
Cause : Carrier Tape Sprocket Hole not engaged with the sprocket teeth.
Remedy
: Lock the suppressor with the front hook.
Cause : Front hook has not locked properly and the suppressor does not hold
the tape securely.
Chip component or foreign
substances including debris
11.3 Tape Feed not correctly performed
OM-1743
11-4
1209-001
Notice
Chip component or foreign
substances including debris
Remedy
: Remove any chip component or foreign substance such as debris attached onto the
sprocket and completely clean the sprocket.
Cause : Chip component or foreign substances including debris have been
attached onto the sprocket and the sprocket does not rotate.
Chip component or foreign
substance including debris
Remedy
: Remove any chip component or foreign substance such as debris attached on the chute
and completely clean the surface of the chute.
If the taping component is mounted with any foreign substance attached, the suppressor
might be deformed or a pick-up error occur.
Therefore, clean it.
Cause : Chip component or foreign substances including debris have been
attached onto the chute and the suppressor does not securely hold the
tape.
11.3 Tape Feed not correctly performed
OM-1743
11-5
