1209-001 Notice Chip component or foreign substances including debris Remedy : Remove any chip component or foreign substance such as debris attached onto the sprocket and completely clean the sprocket. Cause : Chip comp…
1209-001
11.3 Tape Feed not correctly performed
Remedy
: Remove any chip component or foreign substance such as debris attached onto the
suppressor and completely clean the suppressor.
Notice
If the taping component is mounted with any foreign substance attached, the suppressor
might be deformed or a pick-up error occur.
Therefore, clean it.
Cause : Chip component or foreign substances including debris have been
attached inside the suppressor and the suppressor does not securely
hold the tape.
Remedy
: Engage the carrier tape sprocket hole with the sprocket teeth.
Cause : Carrier Tape Sprocket Hole not engaged with the sprocket teeth.
Remedy
: Lock the suppressor with the front hook.
Cause : Front hook has not locked properly and the suppressor does not hold
the tape securely.
Chip component or foreign
substances including debris
11.3 Tape Feed not correctly performed
OM-1743
11-4
1209-001
Notice
Chip component or foreign
substances including debris
Remedy
: Remove any chip component or foreign substance such as debris attached onto the
sprocket and completely clean the sprocket.
Cause : Chip component or foreign substances including debris have been
attached onto the sprocket and the sprocket does not rotate.
Chip component or foreign
substance including debris
Remedy
: Remove any chip component or foreign substance such as debris attached on the chute
and completely clean the surface of the chute.
If the taping component is mounted with any foreign substance attached, the suppressor
might be deformed or a pick-up error occur.
Therefore, clean it.
Cause : Chip component or foreign substances including debris have been
attached onto the chute and the suppressor does not securely hold the
tape.
11.3 Tape Feed not correctly performed
OM-1743
11-5
11.4 Cover Tape Take-up Action not performed
Remedy
: Correct the cover tape route.
Incorrect cover tape route
If the cover tape route is incorrect, it might cause a take-up error or feed error.
Cause : Incorrect cover tape route on the take-up tension lever section
Notice
Remedy
: Set the cover tape correctly.
Twist
If the cover tape is set incorrectly, it might cause a take-up error or feed error.
Cause : Twisted cover tape has been set.
Notice
1209-001
11.4 Cover Tape Take-up Action not performed
OM-1743
11-6
