7.7 Nozzle changer for the 6-segment Collect&Place
head
7.7.1 Overview
The placement system is supplied as standard with two Collect&Place heads. As an option, a
nozzle changer can be installed for each Collect&Place head. This enables the nozzle configura-
tion to be changed quickly, thus allowing the Collect&Place head to be quickly adapted to the
needs of the placement process.
The nozzle changer consists of at least one, and up to five magazines, each with twelve nozzle
garages (see Fig. 7.7 - 1
). The magazines are seated on a common support. Each magazine is
centered using two parallel pins and fixed in place with a spring hook.
Magazines for the 9xx and 8xx nozzle types can be set up. The magazines can be arranged as
required.
PLEASE NOTE: 7
Please refer to Section 7.1
on page 161 for information on the nozzle changer for the 12-segment
Collect&Place head. 7
7.7.2 Technical data
7
Nozzle changer for the 6-segment Collect&Place head
Dimensions (length x width x height) 282 mm x 233 mm x 108 mm
Number of nozzle garages Min. 6 / max. 30
Nozzle types 8 xx, 9 xx
Time required to open and close the locking plate < 200 ms
Capacity of the reject bin Approx. 50 nozzles from the 9xx type,
Approx. 5 nozzles from the 8xx type
Pneumatic system Compressed air line 0.53 MPa (5.3 bar)
7 Station extensions User Manual SIPLACE S-27 HM
7.7 Nozzle changer for the 6-segment Collect&Place head Software version SR.503.xx07/2003 US Edition
190
Fig. 7.7 - 1 Nozzle changer for the 6-segment Collect&Place head, overview
(1) Nozzle changer, base
(2) 9xx nozzle magazine
(3) 8xx nozzle magazine
(4) 8xx nozzle discarding device
(5) 9xx nozzle discarding device
(6) Reject bin for discarded nozzles
User Manual SIPLACE S-27 HM 7 Station extensions
Software version SR.503.xx 07/2003 US Edition 7.7 Nozzle changer for the 6-segment Collect&Place head
191
7.7.3 Mode of operation
The nozzles are seated in nozzle garages and are held in place by a movable locking plate. The
locking plate can be moved 12 mm by a pneumatic cylinder. All the nozzles are either clamped or
released, depending on the position of the plate. The default position of the locking plate, i.e. if
there is no nozzle change in progress, is "closed".
There is a positioning fiducial for position detection on each magazine of the nozzle changer. The
magazine locations are identified by numbers 1 to 5 on the nozzle changer. The nozzle garages
in the magazines are numbered consecutively from 1 to 6 (see Fig. 7.7 - 2
).
PLEASE NOTE 7
Special magazines are available upon request (contact SIEMENSDematic for details) and will be
numbered differently. 7
Picking up a nozzle
– The Collect&Place head Z axis moves down.
– The locking plate (item 2 in Fig. 7.7 - 2
) opens and releases the nozzles.
– The nozzle is picked up by the sleeve of the Collect&Place head.
– The Z axis moves up.
Setting down a nozzle
– The locking plate (item 2 in Fig. 7.7 - 2) opens and releases the nozzles.
– The Collect&Place head Z axis moves down and sets the nozzle down.
– The locking plate closes.
– The Collect&Place head Z axis moves up.
Discarding defective nozzles
– The Collect&Place head Z axis moves down 14 mm towards the discarding device (item 4 or
5 in Fig. 7.7 - 1
) and thus moves the defective nozzle into the hole in the discarding device.
– The Z axis moves up again and the nozzle is stripped from the sleeve by spring wires.
– The nozzle drops into the container (item 6 in Fig. 7.7 - 1
).
