1.7 Abbreviations

C&P 1 Collect&Place 1

C&P12 1 Collect&Place head with 12 segments 1

C&P6 1 Collect&Place head with 6 segments 1

CO 1 Component 1

DCA 1 Direct Chip Attach 1

FC 1 Flip chip 1

GND 1 Ground 1

IC 1 Integrated circuit 1

MTC 1 Matrix tray changer 1

P&P 1 Pick&Place 1

PCB 1 Printed circuit board 1

WPTC 1 Waffle-pack tray carrier 1

WT 1 Waffle-pack tray 1

1 Introduction User Manual SIPLACE S-27 HM

1.7 Abbreviations Software version SR.503.xx07/2003 US Edition

User Manual SIPLACE S-27 HM 2 Operational safety

Software version SR.503.xx 07/2003 US Edition 2.1 Safety instructions

2 Operational safety

2.1 Safety instructions

2.1.1 Conventions for the use of hazard symbols

This User Manual contains notes that must be observed to guarantee your personal safety and to

avoid damage to equipment. These notes are highlighted by warning triangles and are indicated

as follows according to the level of risk:

DANGER or

as used in this User Manual means that death, severe injury or considerable damage to equip-

ment will occur if the danger instructions are not followed.

WARNING or

as used in this User Manual means that death, severe injury or considerable damage to equip-

ment may occur if the warning instructions are not followed.

CAUTION or

as used in this User Manual means that slight injury or damage to equipment may occur if the cau-

tion instructions are not followed.

NOTE

as used in this User Manual provides information on the product or indicates a part of the User

Manual that requires particular attention.

2.1.2 Qualified personnel

Qualified or adequately trained personnel means that these people are familiar with the setting up,

operation and maintenance of automatic placement systems and add-on devices and are suitably

qualified, e.g.

– have been trained, instructed or authorized to switch on and off, isolate, earth and identify elec-

trical circuits and system components in accordance with normal safety standards.

– have been trained or instructed in the upkeep and use of appropriate safety equipment in ac-

cordance with normal safety standards.

– have received first aid training.
