2 Operational safety User Manual SIPLACE S-27 HM 2.2 Warning labels Software version SR. 503.xx07/2003 US Edition 32 2.2.2 W arning label W205 2 Item W205 i n Figs. 2.2 - 4 and 2.2 - 5 ( number pe r machine: 8) W ARNING …

100%1 / 222
User Manual SIPLACE S-27 HM 2 Operational safety
Software version SR.503.xx 07/2003 US Edition 2.2 Warning labels
31
2.2.1.2 Warning label W203
2
Item W203 in Figs. 2.2 - 1, 2.2 - 2 and 2.2 - 3 (number per machine: 4)
2.2.1.3 Warning label W204
2
Item W204 in Fig. 2.2 - 1 (number per placement system: 4)
2.2.1.4 Warning label W206
2
Item W206 in Figs. 2.2 - 1, 2.2 - 2 and 2.2 - 3 (number per machine: 7)
2
2
2
DANGER OF CRUSHING!
Reaching in here can lead to injuries to the arms
and hands.
Do not reach into the machine while it is running
2
2
2
DANGER OF CRUSHING!
Reaching in here can lead to injuries to the arms
and hands.
Do not reach into the machine while it is running
2
DANGEROUS VOLTAGES!
The labeled parts are still live when the main power switch is off.
Disconnect the machine from the mains before servicing it.
NAFTA region: RISK OF ELECTRIC SHOCK OR BURN!
2 Operational safety User Manual SIPLACE S-27 HM
2.2 Warning labels Software version SR.503.xx07/2003 US Edition
32
2.2.2 Warning label W205
2
Item W205 in Figs. 2.2 - 4 and 2.2 - 5 (number per machine: 8)
WARNING 2
If you wish to do work on the tape cutter, you must disconnect the machine from the mains sup-
ply and the compressed air supply.
Wait until the operating pressure has dropped to 0 MPa.
Wear robust protective gloves when working on the tape cutter.
2.2.2.1 Warning label W205 on the tape cutter
2
Fig. 2.2 - 4 Warning label W205 on the tape cutter
Item W205, part no. 03009344-01
2
2
2
2
2
2
2
2
RISK OF CUTTING!
Danger of cutting is present even when the
machine is switched off
User Manual SIPLACE S-27 HM 2 Operational safety
Software version SR.503.xx 07/2003 US Edition 2.2 Warning labels
33
2.2.2.2 Warning label W205 on the used tape channel and on the waste tape chute
2
Fig. 2.2 - 5 Warning label W205 on the used tape channel and on the waste tape chute
Item W205, part no. 03009344-01
