Advanced Software Melter Configuration
7-47
Part 1121836_03
E 11/2014 Nordson Corporation
Viewing System Data
Use the System Data screen to view current and historical information.
NOTE: You can also view system data by touching the located at the
bottom of the Home screen.
Administration
Done
Home
System Reset
Display/Save Diagnostics
Recipes
Lockout Communication
Reset Password Display System Data
Off
Done
Home
System Data
Hours Heaters On: 455
Firmware Version: 4;40
Motor Board Firmware Version: 7.2
Unit On Time: (Hours): 383
Time in Standby (Hours): 22
Service Interval: 500
Hours Until Service Alert: 1
1. From the Home Display touch
Master
Controls
2. Touch System, then Administration.
3. Touch Display System Data. Review the information.
4. Touch Done.
Advanced Software Melter Configuration
7-48
Part 1121836_03
E 11/2014 Nordson Corporation
Locking Out Communications
Use Lockout Communication to prevent remote access to the melter while
you are troubleshooting or performing maintenance on the melter.
Administration
Done
Home
System Reset
Display/Save Diagnostics
Recipes
Lockout Communication
Reset Password Display System Data
Off
1. From the Home Display touch
Master
Controls
2. Touch System, then Administration.
3. Touch the Lockout Communication button to toggle it On or Off
4. Touch Done.
Advanced Software Melter Configuration
7-49
Part 1121836_03
E 11/2014 Nordson Corporation
Default User Settings and Ranges
The following details default settings and ranges for user definable melter,
temperature, pump and melter settings.
Temperature Settings
Setting Default Range/Option
Temperature Limits
Over Temp: 15_C (25_F) Minimum: 5_C (10_F)
Maximum: 60_C (110_F)
Under Temp: 25_C (50_F) Minimum: 5_C (10_F)
Maximum: 60_C (110_F)
Ready Delay 60 minutes Minimum: 0 minutes
Maximum: 60 minutes
Automatic Standby Disabled Enabled
Disabled
Auto Standby Start Time 0 minutes Minimum: 0 minutes
Maximum: 1,440 minutes
Auto Heaters Off Time in Auto
Standby Mode
60 minutes Minimum: 0 minutes
Maximum: 1,440 minutes
Auto Exit Standby Time Disabled Enabled
Disabled
Auto Exit Heaters Off Time in
Auto Manual Mode
0 minutes Minimum: 0 minutes
Maximum: 180 minutes
Standby Temp 50_C (100_F) Minimum: 5_C (10_F)
Maximum: 60_C (110_F)
For Melters:
7407039, 7407040, 7407041. 7407042, 7407668 and 7407669
Setting Default Range/Option
External Zones Set Point 176_C (350_F) Minimum: 40_C (100_F)
Maximum: 176_C (350_F)
Internal Zones Set Point 176_C (350_F) Minimum: 40_C (100_F)
Maximum: 176_C (350_F)
Global Set Point 176_C (350_F) Minimum: 40_C (100_F)
Maximum: 176_C (350_F)
For Melters:
7407664, 7407665, 7407666, 7407667, 7407670 and 7407671
Setting Default Range/Option
External Zones Set Point 232_C (450_F) Minimum: 40_C (100_F)
Maximum: 232_C (450_F)
Internal Zones Set Point 232_C (450_F) Minimum: 40_C (100_F)
Maximum: 232_C (450_F)
Global Set Point 232_C (450_F) Minimum: 40_C (100_F)
Maximum: 232_C (450_F)
