Parts 1 1 -52 Part 1121836_03 E 1 1/2014 Nordson Corporation This page intentiona lly left blank.
Parts
11-51
Part 1121836_03
E 11/2014 Nordson Corporation
Item Description
7403812
TWO HAND RELAY,24VDC,PSR-THC4
1053122
MODULE,CONDITIONER,SIGNAL,0-10V,1K ohm
7407139
BOARD,BREAKOUT,VIP-2/SC/FLK20,TB,20POS
7402954
MOTOR DRIVE, 1PH, 240V, 1HP,ATV312H
7407682
MAIN FILTER,480VAC,30A,3P+PE
7407683
SERVICE KIT,LCD MODULE,232℃,ALTAPAIL II
7407684
KIT EXHAUST HOOD,ALTAPAIL II
7403070
MAIN CONTACTER DILM40C
7131129
CIRCUIT BREAKER 16A 2-POLE FAZ-D16/2
7126362
THERMOSTAT 260°C,24V,1A,FASTON 90°
7116858
MELTING PLATE,SMOOTH,VP,GP,D280,VX
7116879
MELTING PLATE,SMOOTH,VP,GP,D286,VX
7116860
melting plate,axial,VP,GP,D286,VX
Parts
11-52
Part 1121836_03
E 11/2014 Nordson Corporation
This page intentionally left blank.
Technical Data
12-1
Part 1121836_03
E 11/2014 Nordson Corporation
Section 12
Technical Data
General Data
Storage temperature - 45° C to + 75 ° C - 49 ° F to + 167 ° F
Min. ambient temperature - 5 ° C 23 ° F
Max. ambient temperature 40 ° C 104 ° F
Humidity 10 to 95 %, not condensing
Max. operating height 3,000 m 299,923.20 cm
Max. material pressure 100 bar 10000 kPa 1450 psi
Degree of protection IP 54
Noise emission 1 m away <70 dB(A)
Motor/pump speed Refer to page 4-9 Output Quantity
Air Consumption
Per cycle (platen up and down) Approx. 400 standard liters
Suitable Containers
AltaPail P/N Container diameter (interior) Max. container height (exterior)
7407039
7407041
7407664
7407666
280 mm 475 mm
7407040
7407042
7407665
7407667
7407668
7407669
7407670
7407671
286 mm 486 mm
