Installation
3-1
Part 1121836_03
E 11/2014 Nordson Corporation
Section 3
Installation
WARNING! Allow only qualified personnel to perform the following tasks.
Follow the safety instructions in this document and all other related
documentation.
Installation Personnel's Experience
The instructions contained in this section are intended for personnel with
experience/authorization in the following fields:
S
Application methods with hot melt adhesive or similar materials
S
Industrial electrical wiring of power and control lines
S
Industrial mechanical installation
S
General knowledge of process control.
Transport
S
Refer to page 12-5, Dimensions and Weights for weight. Use only
suitable transport devices (lift truck or forklift). Do not lift with a crane.
S
If possible, use the pallet on which the bulk melter was delivered, and
fasten the bulk melter to the pallet.
S
Protect from damage, moisture and dust with suitable packing material.
S
Avoid jolts and vibrations.
Storage
Do not store the bulk melter outside! Protect from humidity, dust and
extreme temperature fluctuations (formation of condensation).
Installation
3-2
Part 1121836_03
E 11/2014 Nordson Corporation
Hardware Installation Tasks
S
Verify that the required installation conditions and utilities exist.
S
Unpack and inspect the melter.
S
Mount the melter on the parent machine or support structure.
S
Configure the electrical service.
S
Connect hot melt hoses and applicators and/or handguns.
S
Connect a compressed air supply.
S
(Optional) Install inputs and outputs.
S
Set up the melter for gear-to-line operation.
S
(Optional) Connect an applicator driver, pattern controller, or timer.
Customer's
Installation
3-3
Part 1121836_03
E 11/2014 Nordson Corporation
Unpacking
Unpack carefully and check for damage caused during transport. Save pallet
and fastening and packing material for later use, or dispose of properly
according to local regulations.
Lifting (Unpacked Bulk Melter)
Refer to page 12-5, Dimensions and Weights for weight. Lift only with a
suitable floor conveyor (lift truck or forklift). Do not lift with a crane.
Setting Up
S
Set up only in an environment that corresponds to the stated Degree of
Protection. Refer to page 12-1,Technical Data. Do not set up in a
potentially explosive environment!
S
Protect from vibration. Remove transport protection (if present).
S
Make sure there is sufficient clearance around the system, especially
above it. Refer to page 12-5, Dimensions and Weights for dimensions.
S
Observe the minimum hose bending radius (Refer to the hose manual).
Exhausting Material Vapors
Make sure material vapors do not exceed the prescribed limits. Refer to the
Material Safety Data Sheet (MSDS) sheet that came with the adhesive for
first aid, handling/storage, exposure and personal protection information.
If necessary, exhaust material vapors and/or provide sufficient ventilation of
the location of the equipment.
Figure 3-1 Principle drawing
