Technical Data
12-1
Part 1121836_03
E 11/2014 Nordson Corporation
Section 12
Technical Data
General Data
Storage temperature - 45° C to + 75 ° C - 49 ° F to + 167 ° F
Min. ambient temperature - 5 ° C 23 ° F
Max. ambient temperature 40 ° C 104 ° F
Humidity 10 to 95 %, not condensing
Max. operating height 3,000 m 299,923.20 cm
Max. material pressure 100 bar 10000 kPa 1450 psi
Degree of protection IP 54
Noise emission 1 m away <70 dB(A)
Motor/pump speed Refer to page 4-9 Output Quantity
Air Consumption
Per cycle (platen up and down) Approx. 400 standard liters
Suitable Containers
AltaPail P/N Container diameter (interior) Max. container height (exterior)
7407039
7407041
7407664
7407666
280 mm 475 mm
7407040
7407042
7407665
7407667
7407668
7407669
7407670
7407671
286 mm 486 mm
Technical Data
12-2
Part 1121836_03
E 11/2014 Nordson Corporation
Exhaust Hood (Accessory)
Nominal air quantity (recommendation) 205 m
3
/h
Pressure loss at nominal air quantity Approximately 50 Pa
Connecting Sleeve
« 100 mm
Technical Data
12-3
Part 1121836_03
E 11/2014 Nordson Corporation
Temperatures
CAUTION: The temperature setting is determined by the processing
temperature prescribed by the material supplier. You cannot exceed the
maximum operating temperature for the system and heated components.
For Melters:
7407039, 7407040, 7407041, 7407042, 7407668 and 7407669
Item Software Limit System Limit
Min. operating temperature (set point) 40 ° C 100 ° F
Max. operating temperature 176 ° C 350 ° F
Over temperature shutdown by thermostat 210 ° C 410 ° F
For Melters:
7407664, 7407665, 7407666, 7407667, 7407670 and 7407671
Item Software Limit System Limit
Min. operating temperature (set point) 40 ° C 100 ° F
Max. operating temperature 232 ° C 450 ° F
Over temperature shutdown by thermostat 260 ° C 500 ° F
Temperature sensor type Ni 120
Electrical Data
WARNING! The unit is designed for only one operating voltage. Operate only
at the operating voltage shown on the ID plate.
Available Operating
Voltages
240 VAC 3-phase without neutral (Delta)
400/230 VAC 3-phase with neutral (Star - WYE)
480 VAC 3-phase without neutral (Delta)
NITE: 400/230 VAC is for electrical service with neutral (WYE) where the
400 VAC us a line-to-line voltage and 230 VAC is a line-to-neutral voltage.
Permitted Deviation from
Operating Voltage
¦ 10%
Operating Voltage
Frequency
50/60 Hz
Maximum Power output per
Heating Channel
NOTE: Each receptacle supplies two heating channels 1000 W but also
maximum 1200 W per receptacle Hose/Applicator, and for receptacle
pairs - maximum 2000 W total per pair.
NOTE: Pairs of receptacles:
* Hose/Gun 1
* Hose/Gun 2
