Advanced Software Me lter Configuration 7 -7 Part 1121836_03 E 1 1/2014 Nordson Corporation Defining Ready Delay Settings Use Rea dy Delay to define the amount of time you want to e lapse afte r all of zones have rea che…
Advanced Software Melter Configuration
7-6
Part 1121836_03
E 11/2014 Nordson Corporation
Defining a Global Set Point Temperature for All Applicators
Use global set point temperature to configure only the applicators with a
uniform set point temperature.
For Melters:
7407039, 7407040, 7407041. 7407042, 7407668 and 7407669
Default Minimum Maximum
176°C (350°F) 40°C (100°F) 176°C (350°F)
For Melters:
7407664, 7407665, 7407666, 7407667, 7407670 and 7407671
Default Minimum Maximum
232°C (450°F) 40°C (100°F) 232°C (450°F)
NOTE: Defining a global set point temperature enables previously disabled
zones.
Temperature
Done
Home
Global Set Point
Temperature Limits
Set Point - All Applicators
Set Point - All Hoses
Done
Cancel
7 8 9
4 5 6
1 2 3
0
Set Point - All Applicators
176
Home
C
o
1. From the Home Display touch
Master
Controls
2. Touch Settings, then Temperature.
3. Touch Set Point - All Applicators and enter the set point temperature
you want for all available applicators.
4. Touch Done.
Advanced Software Melter Configuration
7-7
Part 1121836_03
E 11/2014 Nordson Corporation
Defining Ready Delay Settings
Use Ready Delay to define the amount of time you want to elapse after all of
zones have reached their set point temperatures before the melter
Ready\OK status appears.
Default Minimum Maximum
0 (Zero) minutes 0 (Zero) minutes 60 minutes
NOTE: The ready delay time only functions when the temperature of the
platen, at the time the melter is turned on, is more than 27 °C (50 °F) from its
set point temperature.
NOTE: The ready delay time begins when all components are within 3 °C (5
°F) of their respective set point temperatures.
Accessing Ready Delay Settings
Settings
Done
Home
Temperature
Input
Ready Delay
Standby
Output Pump
Done
Cancel
7 8 9
4 5 6
1 2 3
0
Ready Delay
0
Home
min
1. From the Home Display touch
Master
Controls
2. Touch Settings, then Ready Delay.
3. Enter the number of minutes you want to delay the Ready\OK melter
status.
4. Touch Done.
Advanced Software Melter Configuration
7-8
Part 1121836_03
E 11/2014 Nordson Corporation
Defining Standby Settings Settings
Use the standby option to reduce the set point temperature of all heated
zones (platen, hoses and applicators) while the melter is temporarily not in
production, such as during shift changes.
Item Default
Automatic Standby Disabled
Auto Exit standby Time Disabled
The benefits of making use of the standby option include:
S
Allows for quicker ready for production time between shift changes,
since the heated zones are by default only within 50 °C (100 °F) of
their set point temperatures.
S
Conserves power usage.
About Standby Operation Options
There are two methods of Standby operation:
Standby
Operation
Description
Automatic Allows you to define under what melter conditions
to automatically enter and exit Standby mode.
NOTE: Refer to the following section for more
information.
Manual Allows you to manually enter and exit Standby
mode.
