Advanced Software Melter Configuration
7-8
Part 1121836_03
E 11/2014 Nordson Corporation
Defining Standby Settings Settings
Use the standby option to reduce the set point temperature of all heated
zones (platen, hoses and applicators) while the melter is temporarily not in
production, such as during shift changes.
Item Default
Automatic Standby Disabled
Auto Exit standby Time Disabled
The benefits of making use of the standby option include:
S
Allows for quicker ready for production time between shift changes,
since the heated zones are by default only within 50 °C (100 °F) of
their set point temperatures.
S
Conserves power usage.
About Standby Operation Options
There are two methods of Standby operation:
Standby
Operation
Description
Automatic Allows you to define under what melter conditions
to automatically enter and exit Standby mode.
NOTE: Refer to the following section for more
information.
Manual Allows you to manually enter and exit Standby
mode.
Advanced Software Melter Configuration
7-9
Part 1121836_03
E 11/2014 Nordson Corporation
Accessing Standby Settings
Settings
Done
Home
Temperature
Input
Ready Delay
Standby
Output Pump
Standby Settings
Done
Home
Auto Standby Start Time Platen Standby
Temp Offset
Hoses Standby
Temp Offset
Applicator Standby
Temp Offset
Auto Heaters Off Time
Auto Exit Standby Time
Auto Exit Standby Time
Enabled
Automatic Standby
60 min.
60 min.
60 min.
60_C
60_C
60_C
Enabled
1. From the Home Display touch
Master
Controls
2. Touch Settings, then Standby.
3. Do the following to continue.
Touch Description
Automatic Standby
Enabled
Enables the system the ability to automatically place the melter into
standby mode.
Default: Disabled
Auto Exit Standby Time
Enabled
Enables the system the ability to automatically exit the melter out of
standby mode.
Default: Disabled
Advanced Software Melter Configuration
7-10
Part 1121836_03
E 11/2014 Nordson Corporation
Touch Description
Note: You must have the Automatic Standby option Enabled to make use of the following:
Auto Standby Start Time
60 min.
Define the elapsed time of melter inactivity before the melter
automatically enters standby mode.
Default is 0 (zero) minutes
Minimum time is 0 (zero) minutes
Maximum time is 60 minutes
Auto Heaters Off Time
60 min.
Define the amount of time that must elapse after the automatic
standby time ends before the heaters automatically switch Off.
Default is 0 (zero) minutes
Minimum time is 0 (zero) minutes
Maximum time is 60 minutes
Note: You must have the Auto Exit Standby Time option Enabled to make use of the following:
Auto Exit Standby Time
60 min.
Define the amount of time that must elapse after the automatic
standby time ends before exiting out of standby mode and into normal
operation.
Default is 0 (zero) minutes
Minimum time is 0 (zero) minutes
Maximum time is 60 minutes
Note: The following offset standby temperature settings apply whether the melter was automatically or
manually placed into standby mode.
Platen Standby
Temp Offset
60_C
Define the number of degrees, from the set point temperature, of the
platen that you want to decrease while in standby mode.
Default is 60_C (120_F)
Minimum temp is 5_C (10_F)
Maximum temp is 60_C (120_F)
Hoses Standby
Temp Offset
60_C
Define the number of degrees, from the set point temperature, of all
enabled hoses that you want to decrease while in standby mode.
Default is 50_C (100_F)
Minimum temp is 5_C (10_F)
Maximum temp is 60_C (120_F)
Applicator Standby
Temp Offset
60_C
Define the number of degrees, from the set point temperature, of all
enabled applicators that you want to decrease while in standby mode.
Default is 50_C (100_F)
Minimum temp is 5_C (10_F)
Maximum temp is 60_C (120_F)
