137/144
7 P_SYS_CONF 0x2000 25 do not save BMPs with
automatic data
evaluation
7 P_SYS_CONF 0x20000 26 indicate solder joint
statistics with dpm
138/144
7 P_SYS_CONF 0x40 27 limit exceeded: write
inspection plan name
in file
7 P_SYS_CONF 0x400 28 translate defect
features into text
(when they are defined
in defect definitions.
20 P_AOI_CNTRL 0x1 29 control of automatic
operation switched on
by VPC
20 P_AOI_CNTRL 0x2 30 do not display dialogue
"Warning limit
exceeded"
20 P_AOI_CNTRL 0x4 31 control of AOI switched
on through VPC
7 P_SYS_CONF 0x40000 32 sort data fields in
ascending order
according to index
before evaluation
7 P_SYS_CONF 0x8 33 count one defect per
component
7 P_SYS_CONF 0x80 34 limit exceeded: write
inspection plan name
from si.name
7 P_SYS_CONF 0x8000 35 end program after
automatic start of data
evaluation
7 P_SYS_CONF 0x80000 36 count one defect per
solder joint and single
139/144
panel
8 P_AUTO_SAVE 0x1 37 automatically save
configurations when
modified
8 P_AUTO_SAVE 0x2 38 automatically save
configurations after
evaluation
9 P_CHECK_IP 0x1 39 globally activate
automatic inspection
plan change
9 P_CHECK_IP 0x10 40 skip time filter setting
9 P_CHECK_IP 0x2 41 no difference between
front and back track
9 P_CHECK_IP 0x4 42 read-in current
inspection plan name
with first evaluation
9 P_CHECK_IP 0x8 43 no warning, when
several inspection plan
filters
10 P_CHECK_LW_COLOR Number 44 color for warning limit
and exceeded bars
11 P_CHECK_Y_LIMIT 0x1 45 show notice when
diagram type 3 limit is
exceeded
12 P_CHECK_IP_CHARS Value 46 number of characters
to which the inspection
plan from si.name can
be shortened
13 P_CHECK_LW_COUNT Number 47 maximum number of
