4.5 Manual Observation of the VPC Files

The utility VpcExplorer allows the observation of VPC and VPM files. A detailed

description of the utility can be found in the appendix.

4.6 Checklist for Correct Data Flow

4.6.1 AOI:

• VIS_NAME defined

• File si.par configured (P_VPC_DEST (354),·P_REP_GOOD (56))

• The "Outgoing" directories should exist on the AOI (only necessary when

using Rep_server/Rep_client)

• SI_sj.cnt configured or define #CLE_PINS

• Connecting the repair station as R:\

• Connecting the VPC Server as S:\

4.6.2 Repair station:

• Repair station name defined

• Configure rep.par (P_VPC_USE (258),·P_PPM (25))

• Connecting the VPC Server as S:\

4.6.3 VPC Server:

• Determining the data evaluation

- on data server or

- on local VPC computer

• Clear default definition:

Suggestion: VPC data server installed on repair station

83/144

4.7 Exercise 1:

1. Please make all the settings necessary to write or evaluate VPC files

2. Now load the inspection plan Teach_auto and start the inspection

operation (user: SI_teach). Then stop the inspection operation after

about 5 complete runs.

3. Please check if the VPC files are correctly written.

4. Then start the repair station (user: rep_teach) and confirm the defect.

5. Please check if the VPC files are copied to the VPC server.

6. Please change the user in VPC_teach.

7. With the utility VPC Explorer, check if the classification results and the

number of solder joints are entered in the VPC files

8. Are the machine and repair station names entered?
