User Manual For Cyclone LC Programmers 144
$A006: Faulty external memory card.
$A007: Failed during internal memory verification
$A008: Failed during external memory card verification
$A009: Error while reading external memory card for image pointer
$A00A: Error: Read-only lock is enabled in the external memory card.
15.16 Serial Number Related Errors
$B001: Error erasing the serial number storage
$B002: Error writing serial number
$B003: Serial number is over the limit, up to 255 can be supported at a time
$B004: Error loading Serial Number structure from reset
$B005: Error during serial number structure update
$B006: Error: Serial Number structure was not found.
$B007: Error: Serial Number structure is invalid
$B008: Error programming Serial Number to target.
$B009: Error obtain Serial Number from storage.
15.17 Download Count Related Errors
$C001: Error erasing the download counts storage
$C002: Error writing the download counts
$C003: Download counts is over the limit, up to 255 can be supported at a time
$C004: Error trying to convert the download counts structure
15.18 System Hardware/Firmware/Logic Recoverable Errors
$D001: Error: Firmware does not exist
$D002: Error: Firmware update is not allowed
$D003: Error: Firmware update has failed
$D004: Error: There is a firmware mismatch during firmware update.
$D005: Error: Voltage calibration failure.
$D006: Error: Cannot either read or write disk
User Manual For Cyclone LC Programmers 145
16 CYCLONE FEATURE OVERVIEW / COMPARISON
Cyclone LC vs. Cyclone FX Features
Support For
Multiple
Manufacturers &
Architectures
Cyclone LC Cyclone FX
PEmicro-supported ARM Cortex devices (see
pemicro.com/arm for complete list:
– Microchip (Atmel): SAMxxx
– Cypress: PRoC-BLE, PSoc4, PSoc5
– Infineon: XMC
– NordicSemi: nRF51, nRF52
– NXP: Kinetis, LPC
– OnBright: OB90Rxx
– Silergy (Maxim): MAX716xx
– Silicon Labs: EFM32, EFR32, SiM3
– STMicroelectronics: STM32
– Texas Instruments: LM3S, LM4,
TM4C12x
– Toshiba: TX00, TX03, & TX04
Depending on the model, your Cyclone may also
support these NXP 8-/16-/32-bit architectures (see
Cyclone Models, below):
• S32
• ColdFire® V2/V3/V4
• ColdFire+/V1
• MPC5xx/8xx
• Qorivva® (MPC5xxx)
• DSC
• ARM® Nexus (MAC7xxx)
• S12Z
• HC(S)12(X)
• HCS08
• HC08
• RS08
• STMicroelectronics SPC5, STM8
Touchscreen
Navigation
& Control
Cyclone LC Cyclone FX
• 4.3" Touchscreen Display
• Easily navigable LCD menu
• Can be used to perform Stand-Alone
Programming (SAP) operations
User Manual For Cyclone LC Programmers 146
Extended Security
Features
Cyclone LC Cyclone FX
• Anti-tamper technology
• Internal memory protection &
encryption
• ProCryption Security Activation
License enables RSA/AES
encryption and programming
limits
• Anti-tamper technology
• Internal memory protection &
encryption
• RSA/AES encryption of
programming images
• Limit image programming to a
date range
• Limit # of programming
operations
USB Expansion
Port Functionality
Cyclone LC Cyclone FX
- • Barcode scanner can be used
during programming process
On-Board
Storage
Cyclone LC Cyclone FX
16MB, up to 8 programming
images
1GB, no practical limit to # of pro-
gramming images
High-Speed
Target
Communications
Cyclone LC Cyclone FX
Very fast Extremely fast: Up to 75 Mb/s
Cyclone Models
(PEmicro Part #)
Cyclone LC Cyclone FX
• CYCLONE-LC-ARM: Supports
a variety of ARM cortex MCU's
• CYLONE-LC-UNIVERSAL:
Supports a variety of ARM
cortex MCU's as well as
STMicroelectronics SPC5,
STM8, and NXP's Kinetis, LPC,
S32, Qorivva (MPC5xxx),
MPC5xx/8xx, DSC, S12Z,
RS08, S08, HC08, HC(S)12(X),
and ColdFire MCU's
• CYCLONE-FX-ARM:
Supports a variety of ARM
cortex MCU's
• CYLONE-FX-UNIVERSAL:
Supports a variety of ARM
cortex MCU's as well as
STMicroelectronics SPC5,
STM8, and NXP's Kinetis,
LPC, S32, Qorivva
(MPC5xxx), MPC5xx/8xx,
DSC, S12Z, RS08, S08,
HC08, HC(S)12(X), and
ColdFire MCU's
Powerful
LCD Menu
Cyclone LC Cyclone FX
• Executes SAP operations
• Selects SAP image
• Configures Cyclone IP settings
• Displays operation status
Cyclone LC vs. Cyclone FX Features
