User Manual For Cyclone LC Programmers 146
Extended Security
Features
Cyclone LC Cyclone FX
• Anti-tamper technology
• Internal memory protection &
encryption
• ProCryption Security Activation
License enables RSA/AES
encryption and programming
limits
• Anti-tamper technology
• Internal memory protection &
encryption
• RSA/AES encryption of
programming images
• Limit image programming to a
date range
• Limit # of programming
operations
USB Expansion
Port Functionality
Cyclone LC Cyclone FX
- • Barcode scanner can be used
during programming process
On-Board
Storage
Cyclone LC Cyclone FX
16MB, up to 8 programming
images
1GB, no practical limit to # of pro-
gramming images
High-Speed
Target
Communications
Cyclone LC Cyclone FX
Very fast Extremely fast: Up to 75 Mb/s
Cyclone Models
(PEmicro Part #)
Cyclone LC Cyclone FX
• CYCLONE-LC-ARM: Supports
a variety of ARM cortex MCU's
• CYLONE-LC-UNIVERSAL:
Supports a variety of ARM
cortex MCU's as well as
STMicroelectronics SPC5,
STM8, and NXP's Kinetis, LPC,
S32, Qorivva (MPC5xxx),
MPC5xx/8xx, DSC, S12Z,
RS08, S08, HC08, HC(S)12(X),
and ColdFire MCU's
• CYCLONE-FX-ARM:
Supports a variety of ARM
cortex MCU's
• CYLONE-FX-UNIVERSAL:
Supports a variety of ARM
cortex MCU's as well as
STMicroelectronics SPC5,
STM8, and NXP's Kinetis,
LPC, S32, Qorivva
(MPC5xxx), MPC5xx/8xx,
DSC, S12Z, RS08, S08,
HC08, HC(S)12(X), and
ColdFire MCU's
Powerful
LCD Menu
Cyclone LC Cyclone FX
• Executes SAP operations
• Selects SAP image
• Configures Cyclone IP settings
• Displays operation status
Cyclone LC vs. Cyclone FX Features
User Manual For Cyclone LC Programmers 147
Multiple
Communications
Interfaces
Cyclone LC Cyclone FX
USB 2.0 Full Speed USB 2.0 High-Speed
• Ethernet: 10/100 baseT
• Serial Baud 115200, no parity, 8 data bits,
1 stop bit (adjustable to 57600 Baud for
RS232 controlled production environment)
Additional
Storage - SDHC
Memory Card
Support
Cyclone LC Cyclone FX
• Available with SDHC Port
Activation License
• Via SDHC Port
• SD Card can store more than
200 images.
Versatile
Power
Management
Cyclone LC Cyclone FX
• Uses electromechanical relays to
automatically cycle target power when
necessary.
• Jumper-settable power management
schemes.
Multiple
Voltage
Operation
Cyclone LC Cyclone FX
• Automatically detects and caters to target
voltages ranging from 1.8V to 5V.
Multiple Target
Communication
Modes
Cyclone LC Cyclone FX
• Supports the following communications modes:
– 6-Pin Regular Debug Connector BDM/JTAG Mode
– 10-Pin Regular Debug Connector BDM/JTAG Mode
– 14-Pin Regular Debug Connector Nexus/JTAG Mode
– 16-Pin Regular Debug Connector MON08 Mode
– 20-Pin Regular Debug Connector JTAG/SWD Mode
– 26-Pin Regular Debug Connector BDM/ JTAG Mode
– Mini 10-Pin Mini Debug Connector JTAG/SWD Mode
– Mini 20-Pin Mini Debug Connector JTAG/SWD Mode
• User-selectable target communication speed.
Multiple
SAP Images
Cyclone LC Cyclone FX
• Onboard flash memory stores up to 8 images.
• Images for different architectures can co-exist.
Multiple Memory
Modules In One
SAP Image
Cyclone LC Cyclone FX
• Supports multiple programming algorithms
for internal or external memory modules
such as EEPROM and Flash.
Cyclone LC vs. Cyclone FX Features
User Manual For Cyclone LC Programmers 148
Automatic Serial
Number Mechanism
Cyclone LC Cyclone FX
• Supports serial number programming and
automatic incrementing
• Supports multiple serial number structures
within each SAP Image.
Powerful
Cyclone Control
Suite for
Production Control
Cyclone LC Cyclone FX
Standard Features:
• Control a Cyclone via
USB, Serial, or Ethernet
connections
• Select and Launch Images
by Name or Enumeration
• Recover programming
result and descriptive error
information
• Use automatically counting
local (Cyclone stored)
serial numbers
• Add/Remove/Update a
single image in the
Cyclone
• Read/write Cyclone
properties
• Read Image and target
Properties and Status
Advanced Cyclone Control Suite
License available separately
Standard Features, Plus
These Advanced Features:
• Add/Remove/Update many
images in the Cyclone
• Remote Display Access and
the ability to “touch” the
screen
• Simultaneously (Gang)
Control multiple Cyclones via
the USB, Serial, or Ethernet
connections
• Program (and Read) Dynamic
Data in addition to fixed image
data
Versatile
Programming
Software
Cyclone LC Cyclone FX
• Free image creation utility, image management
utility, and IP configuration utility
Convenient
LED Display
Cyclone LC Cyclone FX
•Indicates success or failure
Real-Time Clock
Cyclone LC Cyclone FX
• System clock with battery backup, can be
configured to display time and date on the main
screen.
• Time zone can be configured and time can be
updated from the internet.
Production
Environment Ready
Cyclone LC Cyclone FX
• Cyclones feature voltage protection technology.
Cyclone LC vs. Cyclone FX Features
