4 Electrical Section
4-30
Diagnostic
Code
Meaning
Diagnostic
Code
Meaning
80h Disable onboard Super I/O ports and IRQs B0h Check for errors
81h Late POST device initialization B1h Inform Rom Pilot about the end of POST.
82h Detect and install external RS232 ports B2h POST done - prepare to boot operating system
83h Configure non-MCD IDE controllers B4h One short beep before boot
84h Detect existence of parallel ports B5h Terminate Quiet Boot
85h Checking for PnP ISA devices B6h Check password
86h Re-initialize onboard I/O ports B7h Initialize ACPI-BIOS
87h Configure Motherboard Configurable Devices B9h Clear Screen
88h Initialize BIOS Data Area BAh Initialize SMBIOS
89h Enable Non-Maskable Interrupts (NMIs) BCh Clear parity checkers
8Ah Initialize Extended BIOS Data Area BDh Display Multi Boot menu
8Bh Test and initialize PS/2 mouse BEh Clear screen
8Ch Initialize floppy controller BFh Check virus and backup reminders
8Fh Determine number of ATA drives C0h Try to boot with INT 19
90h Initialize hard-disk controllers C1h Initialize POST Error Manager (PEM)
91h Initialize local-bus hard-disk controllers C2h Initialize error logging
92h Jump to UserPatch2 C3h Initialize error display function
93h Build MPTABLE for multi-processor boards C4h Initialize system error handler
95h Install CD ROM for boot C5h PnP dual CMOS
96h Clear huge ES segment register C6h Initialize note dock
97h Fixup Multi Processor table C7h Initialize note dock rate
98h Search for option ROMs. One long, two short beeps on
checksum failure
C8h
Force check
99h Check for SMART Drive C9h Extended checksum
9Ch
Set up Power Management
CBh
Redirect Int. 13h to Memory Technologies Devices
such as ROM, RAM,PCMCIA, and serial disk
9Dh Initialize security engine CCh Redirect Int. 10h to enable remote serial video
9Eh Enable hardware interrupts CDh Redirect Int. 15h to enable remote keyboard
9Fh Determine number of ATA and SCSI drives CEh Initialize digitizer and display message
A0h Test Real Time Clock interrupt D2h Unknown interrupt
A2h Check key lock E0h Check memory mounting
A4h Initialize Typematic rate
A8h Erase F2 prompt
AAh Scan for F2 key stroke
ACh Enter SETUP
AEh Clear Boot flag
4 Electrical Section
4-31
Control Board
Handling Control Board
Note the followings when handling PC boards.
z Do not touch control boards by wet hands.
z Do not handle and place the control boards onto any place where any metal chips are around or easily
stick to the board.
z Before touching the board, wear an antistatic wrist strap and connect it with any metal part of the
machine.
z Do not handle and place the control boards to any place where short circuit may occur.
4 Electrical Section
4-32
Electrodes on Feeder / Feeder Bank
Tape feeder is able to run by receiving an electric signal from machine via feeder bank. When contact
failure occurs between feeder bank and machine, tape feeder may not run normally and steady, and it may
cause component pick-up error.
When electrodes on the feeder bank and the machine get dirty, clean them as follows:
NOTE: When the electrodes are touched by hand or have come into contact with foreign matter, cleaning is
recommended even if no dirt can be observed visually.
ACTION: Use a dry cotton swab or non-woven cloth and gently wipe off any dust on the electrodes. While cleaning
the electrodes, check and make sure that the pins on the electrodes are not bent. When it is found that the
pins are bent, contact us for repair. Continuing to use the tape feeder with its pins bent, pins may scratch the
contact surface of the feeder bank.
Do not use alcohol, water base detergents and organic solvent, such as
thinner, benzene and acetone.
Do not use sandpaper and tools with sharp blade or edge, such as a knife and
a screwdriver.
NOTE: When stubborn stains and dirt are on the electrodes, do not try getting rid of them forcedly. Please contact
us.
Cotton swab
Pin Elec tro de s on ma chineElectrodes on feeder bank
Cotton swab
CFB Side Machine Side
