5 Materials 5-3 Part Name Part No. Qty. (Standard) Remarks Nozzle ID Mark Label ID SEAL P050 LC6-M77DP-00 Ｘ ID SEAL P051 LC6-M77DR-00 Ｘ ID SEAL P052 LC6-M77DS-00X ID SEAL P053 LC6-M77DT-00X ID SEAL P054 LC6-M 77E1-00X ID…
5 Materials
5-2
Standard Accessories
Part Name Part No. Qty.
(Standard)
Remarks
Nozzle (with Nozzle ID Label)
NOZ.P050 ASSY. LC6-M7727-00X
N
OZ.P051 ASSY.
LC6-M7729-00X
N
OZ.P052 ASSY.
LC6-M772B-00X
N
OZ.P053 ASSY.
LC6-M772D-00X
NOZ.P054 ASSY.
LC6-M7735-00X
NOZ.P055 ASSY.
LC6-M772K-01X
NOZ.P056 ASSY.
LC6-M772V-01X
NOZ.P057 ASSY.
LC6-M7731-01X
NOZ.P061 ASSY.
LC6-M772F-00X
NOZ.P062 ASSY.
LC6-M772H-00X
NOZ.P072 ASSY.
LC6-M773B-00X
NOZ.P073 ASSY.
LC6-M773E-00X
NOZ.P005 ASSY.
LC6-M7709-00X
NOZ.P006 ASSY.
LC6-M770B-00X
NOZ.P012 ASSY.
LC6-M770D-00X
NOZ.P013 ASSY.
LC6-M770F-00X
NOZ.P017 ASSY.
LC6-M770H-00X
NOZ.P018 ASSY.
LC6-M770K-00X
NOZ.P019 ASSY.
LC6-M770M-00X
NOZ.P020 ASSY.
LC6-M770P-00X
NOZ.P030 ASSY.
LC8-M771R-00X
NOZ.P031 ASSY.
LC6-M7712-10X
NOZ.P032 ASSY.
LC6-M7714-00X
NOZ.P033 ASSY.
LC6-M7716-01X
NOZ.P034 ASSY.
LC6-M7718-00X
NOZ.P042 ASSY.
LC6-M7724-00X
5 Materials
5-3
Part Name Part No. Qty.
(Standard)
Remarks
Nozzle ID Mark Label
ID SEAL P050
LC6-M77DP-00
Ｘ
ID SEAL P051
LC6-M77DR-00
Ｘ
ID SEAL P052
LC6-M77DS-00X
ID SEAL P053
LC6-M77DT-00X
ID SEAL P054 LC6-M77E1-00X
ID SEAL P055 LC6-M77WD-00X
ID SEAL P056 LC6-M77DY-00X
ID SEAL P057 LC6-M77E0-00X
ID SEAL P061 LC6-M77DU-00X
ID SEAL P062 LC6-M77DV-00X
ID SEAL P072 LC6-M77E6-00X
ID SEAL P073 LC6-M77E7-00X
ID SEAL P005 LC6-M77D5-00X
ID SEAL P006 LC6-M77D6-00X
ID SEAL P012 LC6-M77D7-00X
ID SEAL P013 LC6-M77D8-00X
ID SEAL P017 LC6-M77D9-00X
ID SEAL P018 LC6-M77DA-00X
ID SEAL P019 LC6-M77DB-00X
ID SEAL P020 LC6-M77DC-00X
ID SEAL P030 LC8-M77DF-00X
ID SEAL P031 LC6-M77DG-00X
ID SEAL P032 LC6-M77DH-00X
ID SEAL P033 LC6-M77DJ-00X
ID SEAL P034 LC6-M77DK-00X
ID SEAL P042 LC6-M77DM-00X
5 Materials
5-4
Part Name Part No. Qty.
(Standard)
Remarks
ID SEAL TOOL, ASSY. LC1-M8903-00X 1set
PIN(O RING) LC1-M8911-10X 1
Support Pin (Magnet type)
PIN,MAGNET ASSY.
Signal Cable (Std.)
*
1
HNS. PRE-PROCESS
LG0-M56K0-10X 1
6 m
Select standard or SMEMA
Signal Cable (Std.)
*
1
HNS. POST-PROCESS
LG0-M56K0-20X 1
Signal Cable (SMEMA)
*
1
HNS.SMEMA - SMEMA
LG0-M56K0-00X
WRENCH SET LG0-M89A3-00X
SCREW DRIVER(-) LG0-M89A2-00X
MANOMETER ASSY. LG0-M89A5-00X
HANDLE LG0-M90B9-00X
LENS CLEANER SET LG0-M89A4-00X 1
GREASE SILICON LG0-M89AB-00X 1
LCD MONITOR LC8-M6571-00X 1 17” Normal LCD
KEYBOARD ASSY.(ENG) KW3-M5150-60X 1
MOUSE
*
2 KW3-M5169-04X 1
Recovery Kit LE6-M4512-XXX 1
FDD (USB Attachment)
PCJ-1 LG0-M5C00-00X
NEEDLE KV8-M8887-00X 1
NOZZLE CLEANER KIT LG0-M5J00-00X
COUPLER LG0-M89A1-00X
【NOTE】
*
1: 6 mm signal cable. Select the communication cable from standard or SMEMA type.
*
2: USB Type
