4 Electrical Section
4-15
Serial DI Map
■ Device 2
Address
Bit
No.
Signal Name Address
Bit
No.
Signal Name
0000h 0 Device No. Bit 0 0004h 0 SERVO (F)/READY (F)
1 Device No. Bit 1 1 CANCEL (F)/RESET (F)
2 Device No. Bit 2 2 START (F)
3 Device No. Bit 3 3 CYCLE STOP (F)/ STOP (F)
4 Device Added Information Bit 0 4 RECOVERY (F)/CLEAR (F)
5 Device Added Information Bit 1 5
6 Device Added Information Bit 2 6
7 Output Register Value Bit 0 7 DOCKING (F) / (Right Front)
0001h 0 Output Register Value Bit 1 0005h 0 DOCKING (Left Front)
1 Output Register Value Bit 2 1 Tape Cutter Close (Right Front)
2 Output Register Value Bit 3 2 Tape Cutter Close (Left Front)
3 Output Register Value Bit 4 3 Tape Cutter Close ((Right Rear)
4 Input Register Value Bit 0 4 Tape Cutter Close (Left Rear)
5 Input Register Value Bit 1 5 Y1 Regenerative Resistor Thermal Alarm
6 Input Register Value Bit 2 6 Y2 Regenerative Resistor Thermal Alarm
7 Input Register Value Bit 3 7 X Regenerative Resistor Thermal Alarm
0002h 0 Y-axis OR- 0006h 0 SERVO (R)/ RESET (R)
1 Y-axis OR+ 1 CANCEL (R) / RESET (R)
2 2 START (R)
3 3 CYCLE STOPE (R) / STOP (R)
4 4 RECOVERY (R) / CLEAR (R)
5 5
6 UPS Under backup 6
7 UPS Battery Low 7 DOCKING (Left Rear)
0003h 0 Board Available Input 0007h 0 DOCKING (R)/(Right Rear)
1 Ready Input 1 CTF(Left Rear) Power Relay ON
2 Regenerative Resistor 1 Thermo Alarm 2 CTF(Right Rear) Power Relay ON
3 Regenerative Resistor 2 Thermo Alarm 3 CTF(Left Rear) Connector Check
4 Regenerative Resister 3 Thermo Alarm 4 CTF(Left Rear) Connector Check
5 5
6 6
7 Fixed Camera Illumi, Trigger Invalid 7
4 Electrical Section
4-16
Address
Bit
No.
Signal Name Address
Bit
No.
Signal Name
0008h 0 CFB(F) / (Right Front) Lock (R) 000Ch 0 Entrance Sensor
1 CFB(F) / (Right Front) Lock (L) 1 Entrance Buffer Arrival
2 CFB(F) / (Right Front) Check 2 PCB S Stopper On
3 3 PCB S Stopper Off
4 CFB / (Left Front) Lock (R) 4 Exit Sensor / Exit Buffer Arrival
5 CFB / (Left Front) Lock (L) 5 Exit Buffer Slowdown
6 CFB / (Left Front) Check 6 PCB L Stopper On
7 7 PCB L Stopper Off
0009h 0 CFB(Left Rear) Lock (R) 000Dh 0 Main Clamp Up / Push-up Plate Up
1 CFB(Left Rear) Lock (L) 1 Push-up Plate Down
2 CFB (Left Rear) Check 2 Quick Clamp Down (Front)
3 3
4 CFB(R) / (Right Rear) Lock (R) 4 Quick Clamp Down (Rear)
5 CFB(R) / (Right Rear) Lock (L) 5 Support Pins under Conveyor Rail
6 CFB(R) / (Right Rear) Check 6 AWC-axis ORG
7 7 RTS-1(L) sensor
000Ah 0 ENABLE (F) / ACTIVE (F) 000Eh 0 RTS-1(R) sensor
1 ENABLE (R) / ACTIVE (R) 1
2 CTF(Left Rear) Positioning 2 ANC A Open
3 CTF (Left Rear) Insert Complete (L) 3 ANC A Close
4 CTF (Left Rear) Insert Complete (R) 4 Entrance Buffer Slowdown
5 5 Main Conveyor Slow down L
6 6
7 CTF (Right Rear) Positioning 7 Main Conveyor Arrival S
000Bh 0 CTF (Right Rear) Insert Complete (L) 000Fh 0 Main Conveyor Slowdown S
1 CTF (Right Rear) Insert Complete (R) 1 Main Conveyor Arrival L
2 Conveyor 1 Alarm 2
3 Conveyor 2 Alarm 3
4 Conveyor 3 Alarm 4
5 5
6 6
7 7
4 Electrical Section
4-17
Address
Bit
No.
Signal Name Address
Bit
No.
Signal Name
0010h 0 EMG (F) 0013h 0 Fan (Y2 Motor) Lock
1 Front Cover OPEN Detection 1 Fan (X Motor) Lock
2 Cover Lock On (F) 2 Fan (X Beam) Lock
3 3
4 EMG (R) 4
5 Rear Cover OPEN Detection 5
6 Cover Lock On (R) 6
7 7
0011h 0 SERVO (1:ON) / SERVO ON State 0014h 0 Exit Slowdown (U-turn Conveyor)
1 Air Pressure Down (failure) 1 START SW (U-turn Conveyor)
2 2 PCB Vacuum Sensor
3 3
4 4
5 5
6 6
7 7
0012h 0 Fan (Bottom 1) Lock
1 Fan (Bottom 2) Lock
2 Fan (Top 1) Lock
3 Fan (Top 2) Lock
4 Fan (Regenerative Resister 1) Lock
5 Fan (Regenerative Resister 2) Lock
6
7 Fan (Y1 Motor) Lock
