3 Mechanical Section 3-30 Conveyor Belt Drawings of Multi Conveyor Belt Belt Belt Belt M10/M20 Conveyor B elt List M10 M20 PART NAME PART NO. PART NAME PART NO. A BELT LE7-M9417-00x BELT LE6-M9417-00x B BELT LE7-M9417-10…
3 Mechanical Section
3-29
Maintenance
Quick Clamp
Pushup Plate
Lubricate the rod
Lubricate the rod
3 Mechanical Section
3-30
Conveyor Belt
Drawings of Multi Conveyor Belt
Belt
Belt
Belt
M10/M20 Conveyor Belt List
M10 M20
PART NAME PART NO. PART NAME PART NO.
A BELT LE7-M9417-00x BELT LE6-M9417-00x
B BELT LE7-M9417-10x BELT LE6-M9417-10x
C BELT LE7-M9417-20x BELT LE6-M9417-20x
AC
B
A
B
C
