4 Electrical Section 4-23 ■ Device 12 Address Bit No. Signal Name Address Bit No. Signal Name 0000h 0 Device No. Bit0 0004h 0 CTF(Right Rear) Elevator-axis ORG/OR- 1 Device No. Bit1 1 CTF(Right Rear) Elevator-axis OR+ 2 …
4 Electrical Section
4-22
■ Device 10
Address
Bit
No.
Signal Name Address
Bit
No.
Signal Name
0000h 0 Device No. Bit 0 0004h 0 CTF(Left Rear) Elevator-axis ORG/OR-
1 Device No. Bit 1 1 CTF(Left Rear) Elevator-axis OR+
2 Device No. Bit 2 2 CTF(Left Rear) Pallet Transfer Area Sensor
3 Device No. Bit 3 3 CTF(Left Rear) Shutter Open
4 Device Added Information Bit 0 4 CTF(Left Rear) Shutter Close
5 Device Added Information Bit 1 5
6 Device Added Information Bit 2 6
7 Output Register Value Bit 0 7 CTF(Left Rear) Pallet Check in Stocker
0001h 0 Output Register Value Bit 1 0005h 0
1 Output Register Value Bit 2 1 CTF(Left Rear) Pallet Check on Elevator
2 Output Register Value Bit 3 2
3 Output Register Value Bit 4 3
4 Input Register Value Bit 0 4 CTF(Left Rear) Cover Close
5 Input Register Value Bit 1 5 CTF(Left Rear) Cover Lock
6 Input Register Value Bit 2 6 CTF(Left Rear) Setup Switch
7 Input Register Value Bit 3 7
CTF(Left Rear) Regenerative Resistor Thermal
Sensor
0002h 0 BOARD (Left Rear) ID0 0006h 0 CTF(Left Rear) Hook-axis ORG/OR-
1 BOARD (Left Rear) ID1 1
2 BOARD (Left Rear) ID2 2 CTF(Left Rear) Servo ON State
3 BOARD (Left Rear) ID3 3
4 BOARD (Left Rear) ID4 4
5 BOARD (Left Rear) ID5 5
6 BOARD (Left Rear) ID6 6
7 BOARD (Left Rear) ID7 7
0003h 0 BOARD (Left Rear) ID8
1 BOARD (Left Rear) ID9
2 BOARD (Left Rear) ID10
3 BOARD (Left Rear) ID11
4 BOARD (Left Rear) ID12
5 BOARD (Left Rear) ID13
6 BOARD (Left Rear) ID14
7 BOARD (Left Rear) ID15
4 Electrical Section
4-23
■ Device 12
Address
Bit
No.
Signal Name Address
Bit
No.
Signal Name
0000h 0 Device No. Bit0 0004h 0 CTF(Right Rear) Elevator-axis ORG/OR-
1 Device No. Bit1 1 CTF(Right Rear) Elevator-axis OR+
2 Device No. Bit2 2 CTF(Right Rear) Pallet Transfer Area Sensor
3 Device No. Bit3 3 CTF(Right Rear) Shutter Open
4 Device Added Information Bit0 4 CTF(Right Rear) Shutter Close
5 Device Added Information Bit1 5
6 Device Added Information Bit2 6
7 Output Register Value Bit0 7 CTF(Right Rear) Pallet Detect in Stocker
0001h 0 Output Register Value Bit1 0005h 0
1 Output Register Value Bit2 1 CTF(Right Rear) Pallet Detect on Elevator
2 Output Register Value Bit3 2
3 Output Register Value Bit4 3
4 Input Register Value Bit0 4 CTF(Right Rear) Cover Close
5 Input Register Value Bit1 5 CTF(Right Rear) Cover Lock
6 Input Register Value Bit2 6 CTF(Right Rear) Setup Switch
7 Input Register Value Bit3 7
CTF(Right Rear) Regenerative Resistor Thermal
Sensor
0002h 0 BOARD (R) ID0 0006h 0 CTF(Right Rear) Hook-axis ORG/OR-
1 BOARD (R) ID1 1
2 BOARD (R) ID2 2 CTF(Right Rear) Servo ON State
3 BOARD (R) ID3 3
4 BOARD (R) ID4 4
5 BOARD (R) ID5 5
6 BOARD (R) ID6 6
7 BOARD (R) ID7 7
0003h 0 BOARD (R) ID8
1 BOARD (R) ID9
2 BOARD (R) ID10
3 BOARD (R) ID11
4 BOARD (R) ID12
5 BOARD (R) ID13
6 BOARD (R) ID14
7 BOARD (R) ID15
4 Electrical Section
4-24
Operation Check LED
Port01
Port1
Port21
Port01
Port1
Port2
Port3
Port4
Port5
Teach
FIX1
FIX2
Motion
Motion
Motion
I/O
I/O
I/O
I/O
I/O
I/O
LAN Operation Check LED
System Box Assembly
Control Board used in M10 and M20 is equipped with full digital multi IF function which can control whole
machine system.
<XiO.mini Rev.A - Parts Mounted Side >
CPU Module
