4 Electrical Section 4-18 ■ Device 4 Address Bit No. Signal Name Address Bit No. Signal Name 0000h 0 Device No. Bit 0 0004h 0 Air Pressure: Head A1 / Air Pr essure: Head A1 Bit 0 1 Device No. Bit 1 1 Air Pressure: Head A…

100%1 / 148
4 Electrical Section
4-17
Address
Bit
No.
Signal Name Address
Bit
No.
Signal Name
0010h 0 EMG (F) 0013h 0 Fan (Y2 Motor) Lock
1 Front Cover OPEN Detection 1 Fan (X Motor) Lock
2 Cover Lock On (F) 2 Fan (X Beam) Lock
3 3
4 EMG (R) 4
5 Rear Cover OPEN Detection 5
6 Cover Lock On (R) 6
7 7
0011h 0 SERVO (1:ON) / SERVO ON State 0014h 0 Exit Slowdown (U-turn Conveyor)
1 Air Pressure Down (failure) 1 START SW (U-turn Conveyor)
2 2 PCB Vacuum Sensor
3 3
4 4
5 5
6 6
7 7
0012h 0 Fan (Bottom 1) Lock
1 Fan (Bottom 2) Lock
2 Fan (Top 1) Lock
3 Fan (Top 2) Lock
4 Fan (Regenerative Resister 1) Lock
5 Fan (Regenerative Resister 2) Lock
6
7 Fan (Y1 Motor) Lock
4 Electrical Section
4-18
■ Device 4
Address
Bit
No.
Signal Name Address
Bit
No.
Signal Name
0000h 0 Device No. Bit 0 0004h 0
Air Pressure: Head A1 / Air Pressure: Head A1 Bit 0
1 Device No. Bit 1 1 Air Pressure: Head A1 Bit 1
2 Device No. Bit 2 2 Air Pressure: Head A1 Bit 2
3 Device No. Bit 3 3 Air Pressure: Head A1 Bit 3
4 Device Added Information Bit 0 4 Air Pressure: Head A1 Bit 4
5 Device Added Information Bit 1 5 Air Pressure: Head A1 Bit 5
6 Device Added Information Bit 2 6 Air Pressure: Head A1 Bit 6
7 Output Register value Bit 0 7 Air Pressure: Head A1 Bit 7
0001h 0 Output Register value Bit 1 0005h 0 Air Pressure: Head A1 Bit 8
1 Output Register value Bit 2 1 Air Pressure: Head A1 Bit 9
2 Output Register value Bit 3 2 Air Pressure: Head A1 Bit 10
3 Output Register value Bit 4 3 Air Pressure: Head A1 Bit 11
4 Input Register Value Bit 0 4 Air Pressure: Head A1 Bit 12
5 Input Register Value Bit 1 5 Air Pressure: Head A1 Bit 13
6 Input Register Value Bit 2 6 Air Pressure: Head A1 Bit 14
7 Input Register Value Bit 3 7 Air Pressure: Head A1 Bit 15
0002h 0 AZ-axis 1 OR+ 0006h 0 Air Pressure: Head A2 Bit 0
1 AZ-axis 2 OR+ 1
Air Pressure: Head A2 / Air Pressure: Head A2 Bit 0
2 AZ-axis 3 OR+ 2 Air Pressure: Head A2 Bit 2
3 AZ-axis 4 OR+ 3 Air Pressure: Head A2 Bit 3
4 AZ-axis 5 OR+ 4 Air Pressure: Head A2 Bit 4
5 AZ-axis 6 OR+ 5 Air Pressure: Head A2 Bit 5
6 OR-1(X) 6 Air Pressure: Head A2 Bit 6
7 OR+1(X) 7 Air Pressure: Head A2 Bit 7
003h 0 0007h 0 Air Pressure: Head A2 Bit 8
1 1 Air Pressure: Head A2 Bit 9
2 2 Air Pressure: Head A2 Bit 10
3 3 Air Pressure: Head A2 Bit 11
4 Dispense Head 1 Fluid Shortage 4 Air Pressure: Head A2 Bit 12
5 Dispense Head 2 Fluid Shortage 5 Air Pressure: Head A2 Bit 13
6 Dispense Head 3 Fluid Shortage 6 Air Pressure: Head A2 Bit 14
7 Dispense Head 4 Fluid Shortage 7 Air Pressure: Head A2 Bit 15
4 Electrical Section
4-19
Address
Bit
No.
Signal Name Address
Bit
No.
Signal Name
0008h 0
Air Pressure ; Head A3 / Air Pressure: Head A3 Bit 0
000Ch 0
Air Pressure ; Head A5 / Air Pressure: Head A5 Bit 0
1 Air Pressure ; Head A3 Bit 1 1 Air Pressure ; Head A5 Bit 1
2 Air Pressure ; Head A3 Bit 2 2 Air Pressure ; Head A5 Bit 2
3 Air Pressure ; Head A3 Bit 3 3 Air Pressure ; Head A5 Bit 3
4 Air Pressure ; Head A3 Bit 4 4 Air Pressure ; Head A5 Bit 4
5 Air Pressure ; Head A3 Bit 5 5 Air Pressure ; Head A5 Bit 5
6 Air Pressure ; Head A3 Bit 6 6 Air Pressure ; Head A5 Bit 6
7 Air Pressure ; Head A3 Bit 7 7 Air Pressure ; Head A5 Bit 7
0009h 0 Air Pressure ; Head A3 Bit 8 000Dh 0 Air Pressure ; Head A5 Bit 8
1 Air Pressure ; Head A3 Bit 9 1 Air Pressure: Head A5 Bit 9
2 Air Pressure ; Head A3 Bit 10 2 Air Pressure: Head A5 Bit 10
3 Air Pressure ; Head A3 Bit 11 3 Air Pressure: Head A5 Bit 11
4 Air Pressure ; Head A3 Bit 12 4 Air Pressure: Head A5 Bit 12
5 Air Pressure ; Head A3 Bit 13 5 Air Pressure: Head A5 Bit 13
6 Air Pressure ; Head A3 Bit 14 6 Air Pressure: Head A5 Bit 14
7 Air Pressure ; Head A3 Bit 15 7 Air Pressure: Head A5 Bit 15
000Ah 0
Air Pressure ; Head A4 / Air Pressure: Head A4 Bit 0
000Eh 0
Air Pressure: Head A6 / Air Pressure: Head A6 Bit 0
1 Air Pressure ; Head A4 Bit 1 1 Air Pressure: Head A6 Bit 1
2 Air Pressure ; Head A4 Bit 2 2 Air Pressure: Head A6 Bit 2
3 Air Pressure ; Head A4 Bit 3 3 Air Pressure: Head A6 Bit 3
4 Air Pressure ; Head A4 Bit 4 4 Air Pressure: Head A6 Bit 4
5 Air Pressure ; Head A4 Bit 5 5 Air Pressure: Head A6 Bit 5
6 Air Pressure ; Head A4 Bit 6 6 Air Pressure: Head A6 Bit 6
7 Air Pressure ; Head A4 Bit 7 7 Air Pressure: Head A6 Bit 7
000Bh 0 Air Pressure ; Head A4 Bit 8 000Fh 0 Air Pressure: Head A6 Bit 8
1 Air Pressure ; Head A4 Bit 9 1 Air Pressure: Head A6 Bit 9
2 Air Pressure ; Head A4 Bit 10 2 Air Pressure: Head A6 Bit 10
3 Air Pressure ; Head A4 Bit 11 3 Air Pressure: Head A6 Bit 11
4 Air Pressure ; Head A4 Bit 12 4 Air Pressure: Head A6 Bit 12
5 Air Pressure ; Head A4 Bit 13 5 Air Pressure: Head A6 Bit 13
6 Air Pressure ; Head A4 Bit 14 6 Air Pressure: Head A6 Bit 14
7 Air Pressure ; Head A4 Bit 15 7 Air Pressure: Head A6 Bit 15
