2 Periodical Checks
2-3
Manual Check
Check the followings after turning on the main and READY switch of the mounter.
If the mounter conditions or movements are not normal, an error message will appear on the LCD. Refer to
error messages in the reference manual.
ITEM DESCRIPTION
Main switch
Check if display of MENU screen is normal after starting system.
Ready switch
Check if indicator lights when switch is pressed.
If not, turn off system and turn it on again.
EMERGENCY STOP
switch
Check function by pushing and releasing it.
Origin
Check if heads return to origin properly.
Jog
Check if display of head coordinates is proper.
Make sure there is no unusual noise when head is traveling in each axis (X,Y,Z
and Theta). .
Suction
Check if negative pressures of all heads are within range.
Conveyor
Check conveyor movement by transferring PCB.
Stopper
Check stopper movement.
Clamp
Check clamp movement.
Main Clamp
Check main clamp movement
ANC
Check ANC movement.
Head
Check head movement.
Signal I/O
Check capability of sensors in Signal I/O screen.
Refer to reference manual.
Air Pressure
Check head/nozzle choke and solenoid valve failure.
)
3 Mechanical Section.
X-Y Table
Make sure X and Y axes and ball screws do not give unusual noise when traveling
head.
Check that proper amount of grease is provided.
2 Periodical Checks
2-4
Monthly Check
Check the followings once a month.
ITEM DESCRIPTION
LCD
Clean LCD screen if it is dirty.
Cable
Make sure screws on cable and cables supports are not loose.
Check cables in cable-support stay.
Connector
Make sure connectors are not loosened.
Air Hose
Check piping and joints. Check air hose for leakage.
X-Y motors
Make sure X and Y motors are not abnormally heated.
Theta Motor
Make sure there are no flaws on timing belt and gear.
Make sure there is no interference when head is rotating.
Make sure head torque is enough.
Z Motor
Move head up and down to make sure movement is smooth.
Push up a nozzle with your finger to check if movement is smooth.
Suction
Check negative pressure of all heads. If values of negative pressure are not proper,
clean filters in nozzle shafts. Replace filters of vacuum ejector if dirty.
Conveyor
Check conveyor movement and the belt tension, make sure conveyor has no flaws,
abrasions and obstacles.
Check movement of auto-width adjustment to maximum and minimum widths,
and confirm conveyor parallelism and board transfer at entrance and exit.
Stopper
Confirm that Stopper works normally and has no abnormal sound, check no chip
components or other obstructions attached on the stopper.
Main Clamp
Check flaws and abrasions.
Buffer Stopper
Check flaws and abrasions.
ANC
Check flaws and abrasions.
Nozzle Holder
Confirm that the nozzle escape is moving smoothly, and then check that there is no
flaw and abrasion on plate springs.
Fixed Camera Clean Lens (Lens Filter). *
)
”Camera” in 3 Mechanical Section.
Teaching Camera Clean Lens. *
)
”Camera” in 3 Mechanical Section.
Camera Illumination
Confirm that illumination is working and check brightness.
2 Periodical Checks
2-5
Operation Switches
Check if all actuators work properly in the Signal I/O screen.
Check emergency stop switch.
Alarm Beacon
Check if all lamps light.
Make sure it is fixed securely.
Hazard Alarm
(continuous high-pitched tone)
Check if alarm sounds.
Warning Alarm
(intermittent high-pitched tone)
Check if alarm sounds.
Cameras (Fixed and Board
Cameras)
Execute “VISION TEST” and check result.
Pickup Coordinates
Check feeder banks.
Electrodes on Feeder Bank
Check the condition.
)
”Electrodes on Feeder / Feeder Bank” in 4 Electrical Section.
Placement
Make sure components are placed on specified places.
