1 Installation 1-1 1 Installation
Multi Conveyor ................................................................................................................. 3-25
Manual Operation ................................................................................................... 3-26
Maintenance ............................................................................................................ 3-27
Conveyor Belt ......................................................................................................... 3-28
4 Electrical Section ........................................................................................ 4-1
Signal I/O ............................................................................................................................ 4-2
Signal Input Monitor ................................................................................................. 4-2
Signal Output Control ............................................................................................... 4-4
Serial I/O ................................................................................................................... 4-5
Serial DO Map .......................................................................................................... 4-6
Serial DI Map ......................................................................................................... 4-15
System Box Assembly ...................................................................................................... 4-22
Vision Operation Check LED ........................................................................................... 4-24
Motion Port Operation Check LED .................................................................................. 4-25
Motion Operation Check LED .......................................................................................... 4-26
Control Board ................................................................................................................... 4-29
Electrodes on Feeder / Feeder Bank ................................................................................. 4-30
Adjustment of Board Detection Sensors ........................................................................... 4-31
Cautions about overall electrical items ............................................................................. 4-33
Computer Virus Prevention and Treatment ...................................................................... 4-34
5 Materials ...................................................................................................... 5-1
Standard Accessories .......................................................................................................... 5-2
Replacement Parts ............................................................................................................... 5-5
Conveyor Belt ..................................................................................................................... 5-6
Standard Nozzles ................................................................................................................ 5-8
6 Additional Function .................................................................................. 6-1
Dispense Head .................................................................................................................... 6-2
Placement of Dispense Head ............................................................................... 6-2
Assembly of Standard Head ................................................................................. 6-4
Placement of O-Ring to Screw Pump ................................................................. 6-6
Placement of Dispense Head ............................................................................... 6-8
DOT STATION ................................................................................................................ 6-12
Placement of Rolled Paper on DOT STATION ................................................ 6-12
Filling Up the Screw Pump ................................................................................. 6-13
CTF40 and CFB-36/E Periodical Maintenance ................................................................ 6-15
1 Installation
1-1
1
Installation
1 Installation
1-2
Installation of Mounter
Environmental Requirements
Install the mounter at the place where the below conditions are met.
Do not do tasks, such as moving the mounter or connecting the mounter with the main switch ON to prevent
electric shock.
■ Ambient Temperature: Accuracy assurance 23 +/-2 degrees centigrade
Operation assurance 10 to 35 degrees centigrade
(The average over a period of 24 hours does not exceed 30 degrees C.)
■ Relative Humidity: 45 to 60 percent, non-condensing
■ Altitude: 1,000 or below above sea level
■ Atmosphere: Dust and corrosive gas free
■ Floor: Floor must be flat and sturdy enough for freedom from vibration during
operation.
■ Power Requirements: 200 VAC +/- 10%, three phase, 50/60 Hz
* 208/220/230/240/380/400/415/440V VAC with optional power
transformer
Power consumption: 1.1KW
Installed capacity: 6.0kVA
Leakage current: 20mA or less
* Power and ground the mounter independently of other machines which may be a
noise source, such as a compressor, welding machine, or reflow soldering machine
with magnetic contacts.
Warning
