5 Materials
5-4
Part Name Part No. Qty.
(Standard)
Remarks
ID SEAL TOOL, ASSY. LC1-M8903-00X 1set
PIN(O RING) LC1-M8911-10X 1
Support Pin (Magnet type)
PIN,MAGNET ASSY.
Signal Cable (Std.)
*
1
HNS. PRE-PROCESS
LG0-M56K0-10X 1
6 m
Select standard or SMEMA
Signal Cable (Std.)
*
1
HNS. POST-PROCESS
LG0-M56K0-20X 1
Signal Cable (SMEMA)
*
1
HNS.SMEMA - SMEMA
LG0-M56K0-00X
WRENCH SET LG0-M89A3-00X
SCREW DRIVER(-) LG0-M89A2-00X
MANOMETER ASSY. LG0-M89A5-00X
HANDLE LG0-M90B9-00X
LENS CLEANER SET LG0-M89A4-00X 1
GREASE SILICON LG0-M89AB-00X 1
LCD MONITOR LC8-M6571-00X 1 17” Normal LCD
KEYBOARD ASSY.(ENG) KW3-M5150-60X 1
MOUSE
*
2 KW3-M5169-04X 1
Recovery Kit LE6-M4512-XXX 1
FDD (USB Attachment)
PCJ-1 LG0-M5C00-00X
NEEDLE KV8-M8887-00X 1
NOZZLE CLEANER KIT LG0-M5J00-00X
COUPLER LG0-M89A1-00X
【NOTE】
*
1: 6 mm signal cable. Select the communication cable from standard or SMEMA type.
*
2: USB Type
5 Materials
5-5
Replacement Parts
Head Manifold Section
Part Name Part No. Qty. Remarks
VALVE ASSY. LE6-M71A2-A0X 4/6
VALVE LE6-M71A2-B0X 4/6 Supply Valve
VALVE LE6-M71A2-C0X 4/6 Breaker valve
SWITCH LE6-M71A2-D0X 4/6 Pressure Switch
FILTER ELEMENT LE6-M71A2-E0X 4/6 Suction Filter Element
FILTER CASE LE6-M71A2-F0X 4/6 Suction Filter Case
SILENCER LE6-M71A2-G0X 4/6 Silencer
NOTE: “Qty.” indicates the quantity required for each machine.
Nozzle Related
Part Name Part No. Qty. Remarks
O RING LC1-M77A5-90X 1 Common for
P005,P006,P013,
P018,P019,P020
RUBB.PAD17 LG0-M77A0-00X 1 Rubber pad for P017
RUBB.PAD18 LG0-M77A1-00X 1 Rubber pad for P018
RUBB.PAD19 LG0-M77A2-00X 1 Rubber pad for P019
RUBB.PAD20 LG0-M77A9-00X 1 Rubber pad for P020
NOTE: “Qty.” indicates the quantity required for each nozzle.
Air Regulator Section
Part Name Part No. Qty. Remarks
FILTER ELEMENT LG0-M86A2-10X 1 For mist separator
NOTE: “Qty.” indicates the quantity required for each machine.
Grease
Part Name Part No. Qty. Remarks
GREASE,AFA LG0-M86A3-00X 1 AFA Grease (70g)
GREASE,AFB LG0-M86A4-00X 1 AFB Grease (70g)
GREASE SILICON LG0-M89AB-00X 1 Silicone Grease (10g)
Electric Section
Part Name Part No. Qty. Remarks
BATTERY,UPS3 LC6-M53H4-100 １ UPS option
5 Materials
5-6
Conveyor Belt
１. M10
