To prevent injury or machine damage in using the mounter, follow the safety guidelines stated below:
■ General
Only trained personnel, who are thoroughly familiar with the mounter, must use the mounter and enter the
work area.
To prevent electric shock and machine damage, never do tasks such as moving the machine, connect the
machine to other equipment, or servicing the machine when the power is on.
To prevent electric shock and machine damage, never touch terminals of electric components when the
power is on. Electric-shock labels are affixed to the machine covers under which the live electrical parts are
placed.
To prevent electric shock, ground the mounter.
Press immediately the emergency stop switch when the machine operates improperly.
To prevent electric shock, do not operate the mounter by wet hands.
■ Operation
The head assembly of the mounter moves at high speeds. To prevent injuries, do not enter head, hands and
a part of your body inside the operating mounter.
To prevent electric shock and machine damage, do not operate the mounter with live parts exposed.
To prevent electric shock and machine damage, do not touch parts in the control unit.
Turn off the main switch, if power failure occurs, to prevent sudden restarting that may cause personal
injury or machine damage.
In teaching mode, axes will move following your operation, to prevent injuries, do not enter head, hands
and a part of the body inside the operating mounter. And, confirm the safety for people around the mounter
and tray feeder.
The mounting heads will move when scanning the nozzle stations, to prevent injures, do not enter head,
hands and a part of the body inside during e operating machine. And, confirm the safety for people around
the mounter and tray feeder.
When doing Tray Teach, the mounting heads will move, to prevent injures, do not enter head, hands , and a
part of the body inside the operating machine. And, confirm the safety for people around the mounter and
tray feeder.
The mounting heads will move when executing ASJ, to prevent injures, do not enter head, hands and a part
of the body when starting ASJ to prevent injures. And, confirm the safety for people around the mounter
and tray feeder.
Warning
4
If JOG operation is executed, the specified motor, conveyor and feeder pallet will move. Do not enter head ,
hands and a part of the body inside operating machine to prevent injures, and confirm the safety around the
mounter and tray feeder.
The specified axis will move when taking the origin. Do not enter head, hands and a part of the body when
taking the origin to prevent injures, and confirm the safety around the mounter and tray feeder. .
If DO function is operated, the specified actuator will function. Do not enter head, hands and a part of the
body if operating DO function to prevent injures, and confirm the safety of people around the mounter and
tray feeder. .
If Actuator is executed, the specified actuator will function. Do not enter head, hands and a part of he body
when operating Actuator to prevent injures, and confirm the safety of people around the mounter and tray
feeder.
If warming up is executed, the specified parts will work. Do not enter head, hands and a part of the body
during warm up to prevent injures, and confirm the safety of people around the mounter and tray feeder.
■ Maintenance
Turn off the main switch before starting maintenance and inspection. However, if it is necessary to do the
operation when the machine power is on, do not enter head, hands and a part of the body when axes are
moving and secure the safety.
Even after the main switch and circuit breaker are turned off, terminals for lead-in wires are still live. Do
not touch them to prevent electric shock.
The motor would be high temperature when they are working or have just stopped, do not touch motors and
motor drivers when doing the machine maintenance.
