Safety Guidelines

To prevent injury or machine damage in using the mounter, follow the safety guidelines stated below:

■ General

Only trained personnel, who are thoroughly familiar with the mounter, must use the mounter and enter the

work area.

To prevent electric shock and machine damage, never do tasks such as moving the machine, connect the

machine to other equipment, or servicing the machine when the power is on.

To prevent electric shock and machine damage, never touch terminals of electric components when the

power is on. Electric-shock labels are affixed to the machine covers under which the live electrical parts are

placed.

To prevent electric shock, ground the mounter.

Press immediately the emergency stop switch when the machine operates improperly.

To prevent electric shock, do not operate the mounter by wet hands.

■ Operation

The head assembly of the mounter moves at high speeds. To prevent injuries, do not enter head, hands and

a part of your body inside the operating mounter.

To prevent electric shock and machine damage, do not operate the mounter with live parts exposed.

To prevent electric shock and machine damage, do not touch parts in the control unit.

Turn off the main switch, if power failure occurs, to prevent sudden restarting that may cause personal

injury or machine damage.

In teaching mode, axes will move following your operation, to prevent injuries, do not enter head, hands

and a part of the body inside the operating mounter. And, confirm the safety for people around the mounter

and tray feeder.

The mounting heads will move when scanning the nozzle stations, to prevent injures, do not enter head,

hands and a part of the body inside during e operating machine. And, confirm the safety for people around

the mounter and tray feeder.

When doing Tray Teach, the mounting heads will move, to prevent injures, do not enter head, hands , and a

part of the body inside the operating machine. And, confirm the safety for people around the mounter and

tray feeder.

The mounting heads will move when executing ASJ, to prevent injures, do not enter head, hands and a part

of the body when starting ASJ to prevent injures. And, confirm the safety for people around the mounter

and tray feeder.

Warning

If JOG operation is executed, the specified motor, conveyor and feeder pallet will move. Do not enter head ,

hands and a part of the body inside operating machine to prevent injures, and confirm the safety around the

mounter and tray feeder.

The specified axis will move when taking the origin. Do not enter head, hands and a part of the body when

taking the origin to prevent injures, and confirm the safety around the mounter and tray feeder. .

If DO function is operated, the specified actuator will function. Do not enter head, hands and a part of the

body if operating DO function to prevent injures, and confirm the safety of people around the mounter and

tray feeder. .

If Actuator is executed, the specified actuator will function. Do not enter head, hands and a part of he body

when operating Actuator to prevent injures, and confirm the safety of people around the mounter and tray

feeder.

If warming up is executed, the specified parts will work. Do not enter head, hands and a part of the body

during warm up to prevent injures, and confirm the safety of people around the mounter and tray feeder.

■ Maintenance

Turn off the main switch before starting maintenance and inspection. However, if it is necessary to do the

operation when the machine power is on, do not enter head, hands and a part of the body when axes are

moving and secure the safety.

Even after the main switch and circuit breaker are turned off, terminals for lead-in wires are still live. Do

not touch them to prevent electric shock.

The motor would be high temperature when they are working or have just stopped, do not touch motors and

motor drivers when doing the machine maintenance.

■ Detailed Items

When unloading the mounter, the center of gravity is changed if movable parts have moved,

the mounter might slip from the unloading equipment (forklift) and you might get injured.

Then, XY axes must be fixed by jigs when the machine will be moved.

If the machine has been installed by improper way, the mechanical or electrical problem might be

occurred. Please confirm the machine installation and power cable connection in advance.

The mounter is assumed to be used with linking other machines in line. If the mounter is used by

stand–alone, some covers which satisfy requirements of EN294/JISB9707 mentioned below

have to be arranged and prepared by customer in order to prevent hands from going inside of

openings.

Even using the mounter in line, there might be the opening space at both sides of the board

transfer sections depending on the machine line constitution. In this case, the covers satisfied the

specifications of EN294/JISB9707 have to be fabricated by customer.

The followings are EN294/JISB9707, specifications of safety distance (upper limb) for

clearance.

If feeders are not set on all feeder stations, it is possible to enter hands inside of the machine from

the space of stations which no feeder is set, and then you could get injured.

Therefore, dummy feeders to put on empty stations have to be purchased or some covers satisfied

EN294/JISB9707 have to be prepared for hands not to be able to enter.

Even if the main switch has been turned off, the main power is still supplied from the terminal

XB11 to QS11. There is the possibility of getting electrical shock, so please do not take out or

dissemble covers.

If the machine has UPS option, there is still residual voltage even the main switch has been turned

off. There is the possibility of getting electrical shock, please do to take out or disassemble

covers.

【Specifications of Safety Distance (upper limb) for Clearanc,EN294/JISB9707】

e：Opening Width Opening Part form; Rectangle (Square )

6＜e≦8 ⇒Safety Distance≧20(15)

8＜e≦10 ⇒ ≧80(25)

10＜e≦12 ⇒ ≧100(80)

12＜e≦20 ⇒ ≧120(120)
