MI L - S TD - 202 -1 1 1 Inches mm Inc h es mm .002 0.05 .3 70 9. 40 .005 0.13 .3 75 9. 53 .081 2.06 . 395 10. 03 .090 2.29 . 405 1 0.29 .095 2.41 . 430 1 0.92 .156 3.96 . 433 1 1.00 .187 4.75 . 443 11.25 .198 5.03 . 500…
MIL-STD-202-111
Inches mm Inches mm
.003 0.08 .300 7.62
.005 0.13 .470 11.94
.011 0.28 .495 12.57
.039 0.99 .500 12.70
.042 1.07 .562 14.27
.046 1.17 .745 18.92
.170 4.32 .750 19.05
.200 5.08 1.187 30.15
MATERIAL: BRASS
BODY-BURNER
FIGURE 1. Burner head - Continued.
3
北测（上海）电子科技有限公司
联系方式：xuyj@beice-sh.com 13917165676
MIL-STD-202-111
Inches mm Inches mm
.002 0.05 .370 9.40
.005 0.13 .375 9.53
.081 2.06 .395 10.03
.090 2.29 .405 10.29
.095 2.41 .430 10.92
.156 3.96 .433 11.00
.187 4.75 .443 11.25
.198 5.03 .500 12.70
.202 5.13 .715 18.16
.250 6.35 .720 18.29
.360 9.14 1.500 38.10
MATERIAL: BRASS
BASE-BURNER
FIGURE 1. Burner head - Continued.
4
北测（上海）电子科技有限公司
联系方式：xuyj@beice-sh.com 13917165676
MIL-STD-202-111
6. NOTES
(This section contains information of a general or explanatory nature that may be helpful, but is not mandatory.)
6.1 Supersession data. The main body and 38 parts of this revision of MIL-STD-202 replace superseded MIL-STD-
202.
Custodians: Preparing activity:
Army - CR DLA – CC
Navy - EC
Air Force - 85 (Project 59GP-2015-015)
DLA - CC
Review activities:
Army - AR, AT, AV, CR4, MI, SM, TE
Navy - AS, OS, SH
Air Force - 19, 99
NSA - NS
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above using the
ASSIST Online database at https://assist.dla.mil/
5
