Communication Interfaces
VTK-TR-BA-171e-1 - User Manual MDS 3080-V
93
20 SETADJLED:OFF
Description:
This command deactivates the control lamps for adjust. This affects the
lamps outside of the adjust:
• The red adjust-LED is ON, if the MDC detects an error (except for an
adjust error)
• The green adjust-LED stays OFF
During the adjust, the adjust-LEDs work as always.
Alternatively, you can deactivate the control lamps for adjust by means of
the service code 1100 (see paragraph 4.5.6 "Submenu “Service-Option”
",
page 33).
Example:
Input:
SETADJLED:OFF
Result:
The control lamps for adjust are deactivated.
Return:
OK
21 SETADJLED:ON
Description:
This command activates the control lamps for adjust. This affects the lamps
outside of the adjust:
• Red: if the MDC detects an error
• Green: the valve detects that the adjust value falls inside the
adjust range.
During the adjust, the adjust-LEDs work as always.
Alternatively, you can activate the control lamps for adjust by means of the
service code 1100 (see paragraph 4.5.6 "Submenu “Service-Option”
",
page 33).
Example:
Input:
SETADJLED:ON
Result:
The control lamps for adjust are activated.
Return:
OK
22 SYSTEM:KLOCK:OFF (KLOCK = Key Lock)
Description:
Access to keypad is permitted, the locking function disabled.
Example:
Input:
SYSTEM:KLOCK:OFF
Result:
The keypad of the control unit can be used.
Return:
OK
23 SYSTEM:KLOCK:ON (KLOCK = Key Lock)
Description:
This command locks the keypad of the control unit. This way, unauthorized
modification of parameters can be prevented.
Example:
Input:
SYSTEM:KLOCK:ON
Result:
The keypad is locked.
Return:
OK
24 SYSTEM:SHOW:CYCLES
Description:
The current value of the cycle counter is indicated.
Example:
Input:
SYSTEM:SHOW:CYCLES
Result:
Current value of the cycle counter.
Return:
1235000
Communication Interfaces
94
VTK-TR-BA-171e-1 - User Manual MDS 3080-V
25 SYSTEM:SHOW:VALVEID
Description:
The valve ID is displayed.
In case the system is in auxiliary mode, the return is “Auxiliary Mode”.
Example:
Input:
SYSTEM:SHOW:VALVEID
Result:
ID of the connected valve.
Return:
Valve ID: 10PEA001
26 SYSTEM:SHOW:CONTROLLERID
Description:
The ID of the control unit is displayed.
Example:
Input:
SYSTEM:SHOW:CONTROLLERID
Result:
ID of the control unit.
Return:
Controller ID: 12060
27 SYSTEM:SHOW:STATUS
Description:
This command sends the current status of KeyLock, First Drop, Fixed
Adjust, DosOK with Delay, SingleDosOK and Auxiliary Mode.
If the status for First Drop or Fixed Adjust is ON, the system sends some
extra information like TNL or adjust value.
Example:
Input:
SYSTEM:SHOW:STATUS
Result:
Settings of the above listed items
Return:
KeyLock: OFF
FirstDrop: OFF
FixedAdjust: OFF
DosOK with Delay: OFF
SingleDosOK: per pulse
Auxiliary Mode: OFF
Communication Interfaces
VTK-TR-BA-171e-1 - User Manual MDS 3080-V
95
28 SYSTEM:FIRSTDROP:OFF
Description:
This command deactivates the first drop function.
Example:
Input:
SYSTEM:FIRSTDROP:OFF
Result:
The first drop mode is deactivated.
Return:
OK
29 SYSTEM:FIRSTDROP:ON
Description:
This command activates the first drop function.
Example:
Input:
SYSTEM:FIRSTDROP:ON
Result:
The first drop mode is activated.
Return:
OK
30 SYSTEM:FIRSTDROP:ADJUST:<starting value>
Description:
This command starts the first drop adjust.
The starting value is between 2 and 50. Further control of the first drop
adjust is done via the commands “KEY:ENTER”, “KEY:ESCAPE” and
“KEY:ADJUST”.
Details you will find in paragraph 8.2.4, page 126.
Example:
Input:
SYSTEM:FIRSTDROP:ADJUST:10
Result:
The first drop adjust is started.
Return:
Fill up with Medium!!!!!
31 SYSTEM:FIXEDADJUST:OFF
Description:
This command deactivates the fixed adjust function.
Example:
Input:
SYSTEM:FIXEDADJUST:OFF
Result:
The fixed adjust mode is deactivated.
Return:
OK
32 SYSTEM:FIXEDADJUST:ON
Description:
This command activates the fixed adjust function.
Example:
Input:
SYSTEM:FIXEDADJUST:ON
Result:
The fixed adjust mode is activated.
Return:
OK
