General Instructions
VTK-TR-BA-171e-1 - User Manual MDS 3080-V
13
3 General Instructions
This chapter summarizes the content of this manual and contains general information for the
user. Some pictures might differ slightly from the actual product.
3.1 How to Use this Manual
• Each step of installation, operation and maintenance has to be performed in accordance with
this manual.
• You can find information about safety aspects and an efficient use of the system in the
concerning chapters.
• This manual represents an integral part of the delivery and must be made available to every
user working with this system. Always keep it in close vicinity.
• It must be preserved until the end of the lifetime of the system.
3.2 Legend
3.2.1 Danger Levels
Instruction Possible Consequences
DANGER!
The damage is imminent!
If the operating procedure is not strictly observed, this situation may result in
death, considerable material damage or environmental contamination.
WARNING!
Warn of a potentially dangerous situation!
The danger of death and serious injuring cannot be excluded.
CAUTION!
Cautions about a potential problem!
Danger of minor or medium injuries.
IMPORTANT NOTE!
Warns about potential damage to the equipment!
An operating procedure which, if not strictly observed, may result in damage
to the equipment, unexpected interruptions or shutdown.
INFORMATION!
Supplementary recommendation for an economical and timesaving use of
the equipment.
Tab. 3: Danger levels
3.2.2 Illustration Convention
Symbol Explanation
Step 1:
Step 2:
The sequence must be followed in correct order
–
Each step of this sequence is mandatory, none of them should be omitted
Direction of movement
•
Lists
[…]
Symbol for a key on the keypad
Tab. 4: Illustration convention
General Instructions
14
VTK-TR-BA-171e-1 - User Manual MDS 3080-V
3.2.3 Abbreviations
Abbr. Full Name
BY
Bayonet
CTF
Ceramics Tappet Flat
CTK
Cleaning Tool Kit
FA
Fixed Adjust
FD
First Drop
MDC
Controller (MicroDispensingControl unit)
MDF
Fluid box (MicroDispensingFluid box)
MDS
MicroDispensingSystem
MDT
Tool (MicrodispensingTool)
MDV
Valve (MicroDispensingValve)
MDX
Supply unit
NFN
Nozzle Fixation Nut
NI
Nozzle Insert
NL
Needle Lift
PDTF
Poly Diamond Tappet Flat
PLC
Programmable Logic Controller
POD
Point of Dispensing
RTC
Real-time clock
TNL
True Needle Lift
TTF
Tungsten carbide Tappet Flat
Tab. 5: Abbreviations
General Instructions
VTK-TR-BA-171e-1 - User Manual MDS 3080-V
15
3.3 Tools
The following tools are required to install and to operate the MDS:
• MDT 301 - Universal Tool (Order no. 1010208)
• MDT 303 - Nozzle Insert Changing Tool (Order no. 1007083)
• MDT 306 - Torque Wrench Tool VM black (Order no. 1015062)
• MDT 307 - Adjust Tool TA Hotmelt Handle (Order no. 1014143)
• MDT 316 - Nozzle Insert Cleaning Tool (Order no. 1013324)
• MDT 323 - Nozzle Insert – Squeezing Out Tool TA (Order no.1014283)
• MDT 324 - Nozzle Insert Cleaning Holder (Order no.1014310)
• MDT 327 - Multi-Function Tool (Order no.1014440)
• MDT 328 - Tappet Sealing Changing Tool (Order no.1014503)
• Hexagon Key Set (Order no. 1012993)
When you order tools, always specify the order number of the required item.
IMPORTANT NOTE
No foreign tools
Do not use auxiliary tools or foreign products, otherwise damages to the equipment might be
possible.
