Communication Interfaces
94
VTK-TR-BA-171e-1 - User Manual MDS 3080-V
25 SYSTEM:SHOW:VALVEID
Description:
The valve ID is displayed.
In case the system is in auxiliary mode, the return is “Auxiliary Mode”.
Example:
Input:
SYSTEM:SHOW:VALVEID
Result:
ID of the connected valve.
Return:
Valve ID: 10PEA001
26 SYSTEM:SHOW:CONTROLLERID
Description:
The ID of the control unit is displayed.
Example:
Input:
SYSTEM:SHOW:CONTROLLERID
Result:
ID of the control unit.
Return:
Controller ID: 12060
27 SYSTEM:SHOW:STATUS
Description:
This command sends the current status of KeyLock, First Drop, Fixed
Adjust, DosOK with Delay, SingleDosOK and Auxiliary Mode.
If the status for First Drop or Fixed Adjust is ON, the system sends some
extra information like TNL or adjust value.
Example:
Input:
SYSTEM:SHOW:STATUS
Result:
Settings of the above listed items
Return:
KeyLock: OFF
FirstDrop: OFF
FixedAdjust: OFF
DosOK with Delay: OFF
SingleDosOK: per pulse
Auxiliary Mode: OFF
Communication Interfaces
VTK-TR-BA-171e-1 - User Manual MDS 3080-V
95
28 SYSTEM:FIRSTDROP:OFF
Description:
This command deactivates the first drop function.
Example:
Input:
SYSTEM:FIRSTDROP:OFF
Result:
The first drop mode is deactivated.
Return:
OK
29 SYSTEM:FIRSTDROP:ON
Description:
This command activates the first drop function.
Example:
Input:
SYSTEM:FIRSTDROP:ON
Result:
The first drop mode is activated.
Return:
OK
30 SYSTEM:FIRSTDROP:ADJUST:<starting value>
Description:
This command starts the first drop adjust.
The starting value is between 2 and 50. Further control of the first drop
adjust is done via the commands “KEY:ENTER”, “KEY:ESCAPE” and
“KEY:ADJUST”.
Details you will find in paragraph 8.2.4, page 126.
Example:
Input:
SYSTEM:FIRSTDROP:ADJUST:10
Result:
The first drop adjust is started.
Return:
Fill up with Medium!!!!!
31 SYSTEM:FIXEDADJUST:OFF
Description:
This command deactivates the fixed adjust function.
Example:
Input:
SYSTEM:FIXEDADJUST:OFF
Result:
The fixed adjust mode is deactivated.
Return:
OK
32 SYSTEM:FIXEDADJUST:ON
Description:
This command activates the fixed adjust function.
Example:
Input:
SYSTEM:FIXEDADJUST:ON
Result:
The fixed adjust mode is activated.
Return:
OK
Communication Interfaces
96
VTK-TR-BA-171e-1 - User Manual MDS 3080-V
33 SYSTEM:DOSOKDELAY:OFF
Description:
This command deactivates the DOSOK-Delay.
When this is true, the length of a delay is not added to the length of the
DOSOK signal. (Default setting is “delay OFF”.)
Example:
Input:
SYSTEM:DOSOKDELAY:OFF
Result:
Deactivates the DOSOK-delay.
Return:
OK
34 SYSTEM:DOSOKAYDELAY:ON
Description:
This command activates the DOSOK-Delay.
When this is true, the length of a delay is added to the length of the DOSOK
signal. (Default setting is “delay OFF”.)
Example:
Input:
SYSTEM:DOSOKDELAY:ON
Result:
Activates the DOSOK-delay.
Return:
OK
35 SYSTEM:SINGLEDOSOK:SETUP
Description:
This command sets the Single-DOSOK signal to “Setup”. The length of the
Single-DOSOK signal is that of the setup. (Default setting is “Pulse”.)
Example:
Input:
SYSTEM:SINGLEDOSOK:SETUP
Result:
The Single-DOSOK is set to “setup”.
Return:
OK
36 SYSTEM:SINGLEDOSOK:PULSE
Description:
This command sets the Single-DOSOK signal to “Pulse”. The length of the
Single-DOSOK signal is that of a pulse. (Default setting is “Pulse”.)
Example:
Input:
SYSTEM:SINGLEDOSOK:PULSE
Result:
The Single-DOSOK is set to “pulse”.
Return:
OK
