Communication Interfaces
VTK-TR-BA-171e-1 - User Manual MDS 3080-V
85
8.1.2.1 Overview
0
RS-232C commands Reaction time (ms)
For baud rate:
9600 bits/s 115200 bits/s
1. *ESR? (e.g. 0 errors)
980
640
2. *ESR2? (e.g. 0 errors)
1590
640
3. *IDN?
80
70
4. *OPC?
50
40
5. ADJUST:?
50
40
6. ADJUST:START
400
340
7. ADJUST:TO:CHANGE:<adjust range>
210
190
8. ADJUST:VAL:FA:?
90
70
9. ADJ:VALUES:?
80
70
10. HEATER:?
inapplicable to the system
11. HEATER:1:OFF
inapplicable to the system
12. HEATER:1:ON
inapplicable to the system
13. HEATER:110V
inapplicable to the system
14. HEATER:230V
inapplicable to the system
15. KEY:ENTER
60
40
16. KEY:ESCAPE
60
40
17. KEY:ADJUST
60
40
18. HELP
1890
640
19. LCD?
390
340
20. SETADJLED:OFF
90
80
21. SETADJLED:ON
90
80
22. SYSTEM:KLOCK:OFF
50
40
23. SYSTEM:KLOCK:ON
50
40
24. SYSTEM:SHOW:CYCLES
50
40
25. SYSTEM:SHOW:VALVEID
90
70
26. SYSTEM:SHOW:CONTROLLERID
90
70
27. SYSTEM:SHOW:STATUS
690
340
28. SYSTEM:FIRSTDROP:OFF
340
320
29. SYSTEM:FIRSTDROP:ON
200
190
30. SYSTEM:FIRSTDROP:ADJUST:<starting value>
90
70
31. SYSTEM:FIXEDADJUST:OFF
380
380
32. SYSTEM:FIXEDADJUST:ON
380
380
33. SYSTEM:DOSOKDELAY:OFF
80
70
34. SYSTEM:DOSOKDELAY:ON
80
60
Communication Interfaces
86
VTK-TR-BA-171e-1 - User Manual MDS 3080-V
RS-232C commands Reaction time (ms)
For baud rate:
9600 bits/s 115200 bits/s
35. SYSTEM:SINGLEDOSOK:SETUP
80
70
36. SYSTEM:SINGLEDOSOK:PULSE
80
60
37. SYSTEM:PASSWORD:<your password>
60
40
38. SYSTEM:PASSWORD:OFF
80
60
39. SYSTEM:PASSWORD:ON
80
60
40. SYSTEM:PASSWORD:SET:<your password>
80
70
41. SYSTEM:AUXILIARYMODE:ON
130
110
42. TEMP:?
inapplicable to the system
43. TEMP:<set point in °C>
inapplicable to the system
44. TRIGGER:SET:?
90
70
45. TRIGGER:SET:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>
60
60
46. TRIGGER:SET:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>,1
90
80
47. TRIGGER:ASET:?
380
340
48. TRIGGER:ASET:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>
70
50
49. TRIGGER:ASET:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>,1
100
80
50. STRIGGER:SET:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>
100
90
51. STRIGGER:SET:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>,1
130
110
52. STRIGGER:ASET:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>
400
350
53. STRIGGER:ASET:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>,1
430
380
54. VALVE:UP
60
40
55. VALVE:DOWN
60
40
56. VALVE:CHECK:OFF
120
110
57. VALVE:CHECK:ON
120
110
58. VALVE:CHECK:<value>
50
40
59. VALVE:OPEN
60
40
60. VALVE:OPEN:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>
70
50
61. VALVE:OPENS<setup no.>
60
40
62. VALVE:AOPEN
60
40
63. VALVE:AOPEN:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>
60
50
64. VALVE:AOPENS<setup no.>
60
40
65. SVALVE:OPEN
90
90
66. SVALVE:OPEN:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>
90
80
67. SVALVE:OPENS<setup no.>
90
340
68. SVALVE:AOPEN
390
340
69. SVALVE:AOPEN:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>
400
350
70. SVALVE:AOPENS<setup no.>
80
340
Communication Interfaces
VTK-TR-BA-171e-1 - User Manual MDS 3080-V
87
RS-232C commands Reaction time (ms)
For baud rate:
9600 bits/s 115200 bits/s
71. WRITE:LCD:<text>
60
40
72. SCENARIO:STATUS
680
340
73. SCENARIO:OFF
90
70
74. SCENARIO:ON
80
70
75. SCENARIO:PLCSTOP:1:OFF
100
90
76. SCENARIO:PLCSTOP:1:ON
100
80
77. SCENARIO:SAVE:<scenario no.>:<values>
100
90
78. SCENARIO:READ:<scenario no.>
680
340
79. SETUP:SAVE:<setup no.>:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>
90
80
80. SETUP:ASAVE:<setup no.>:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>
90
70
81. SETUP:READ:<setup no.>
100
70
82. SETUP:AREAD:<setup no.>
400
340
83. BAUDRATE:0/1/2/3/4
60
40
84. GETTD
90
70
85. MDC:RESTART
210
190
