Maintenance
148
VTK-TR-BA-171e-1 - User Manual MDS 3080-V
Fig. 43: Example - Nozzle Insert N11
10.1.4 Exchange of the Tappet, the Tappet Sealing and the Nozzle Insert
For the necessary steps of de-/mounting the tappet/tappet sealing/nozzle insert, please see the
cleaning chapter (see chapter 9, page 129). Before disassembling the system, perform the
cleaning procedure explained in the same chapter. There you will also find the necessary
information of how to clean the tappet/tappet sealing/nozzle insert.
Error Messages
VTK-TR-BA-171e-1 - User Manual MDS 3080-V
149
11 Error Messages
The following pages list all the error messages you could encounter when using this system. The
table in paragraph 11.1, page 150 will give you a quick overview. In paragraph 11.2, page 151
every error message is explained in detail.
In case of an error, an error message is shown in the display and the red adjust LED is switched
“ON”. This information can also be obtained via pin 13 of the PLC interface (see paragraph 8.2.1
"Pin Functions", page 119). Press [enter] to clear the display. If this does not work, switch “OFF”
the control unit. Check the system for potential problems (e.g. loose cables) and re-start the
system.
If the error still occurs, please contact the Technical Support at VERMES Microdispensing or your
local supplier (see Page 7).
INFORMATION
Storing error messages
After the re-start, the error message can only be found in the submenu “Error” (see
paragraph 4.5.4 "Submenu “Status”", page 31).
Error Messages
150
VTK-TR-BA-171e-1 - User Manual MDS 3080-V
11.1 Table of Error Messages
The following table lists all error messages with their error code and when they might appear.
Error Code Error Message Related to When?
104
104 Sensor Communication Error
Valve
Start-up, Operation
190
190 Incorrect Valve Data
Valve
Start-up, Operation
193
193 Autorange Error pr. Enter
Valve
Operation
199
199 Valve Error Escape for Auxi.
Valve
Start-up
301
301 No Valve Present Error
Valve
Start-up
302
302 Actuator Connection Error
Valve
Operation
501
501 Valve Defect Error
Valve
Start-up
601
601 USART Buffer Overflow
RS-232C
Operation
700
700 MDC Calibr. Wrong pr. Enter
MDC
Start-up
702
702 Watchdog TimeOut pr. Enter
MDC
Start-up, Operation
800
800 wrong H calib pr. Enter
Heater
Start-up
801
801 No Heater! Press Enter
Heater
Start-up, Operation
901
901 RAM Data Error pr. Enter
MDC Data
Start-up, Operation
902
902 EEPROM not formatted Enter
MDC Data
Start-up, Operation
903
903 EEPROM Write Error pr. Enter
MDC Data
Operation
904
904 Setup Save Error pr. Enter
MDC Data
Operation
905
905 Setup Load Error pr. Enter
MDC Data
Operation
999
999 Error in Errorlist
MDC Data
Operation
