Attachments
VTK-TR-BA-171e-1 - User Manual MDS 3080-V
171
14.7 Overview of the Command Functions
Details of the commands listed below are explained in paragraph 8.1.2.2, page 88.
RS-232C commands Functions
1
*ESR? (e.g. 0 errors) Check the latest error codes
2
*ESR2? (e.g. 0 errors) Check the latest error codes with parameters
3
*IDN? Check device information
4
*OPC? Check the last trigger impulses
5
ADJUST:? Check the adjust status
6
ADJUST:START Initiate the adjust
7
ADJUST:TO:CHANGE:<adjust range> Change the parameters for the adjust range
8
ADJUST:VAL:FA:? Check the status of the fixed adjust
9
ADJ:VALUES:? Check the adjust range
10
HEATER:? This command does not work in the MDS 3080-V
11
HEATER:1:OFF This command does not work in the MDS 3080-V
12
HEATER:1:ON This command does not work in the MDS 3080-V
13
HEATER:110V This command does not work in the MDS 3080-V
14
HEATER:230V This command does not work in the MDS 3080-V
15
KEY:ENTER Send ENTER signal to confirm error(s)
16
KEY:ESCAPE Send ESCAPE signal
17
KEY:ADJUST Send the adjust signal
18
HELP Check all RS-232C commands
19
LCD? Check current content of the screen
20
SETADJLED:OFF Deactivate the control lamps for adjust
21
SETADJLED:ON Activate the control lamps for adjust
22
SYSTEM:KLOCK:OFF Unlock the keypad
23
SYSTEM:KLOCK:ON Lock the keypad
24
SYSTEM:SHOW:CYCLES Check the current cycle counter
25
SYSTEM:SHOW:VALVEID Check the valve ID
26
SYSTEM:SHOW:CONTROLLERID Check the MDC ID
27
SYSTEM:SHOW:STATUS Check the status of KeyLock, First Drop, Fixed Adjust, DosOK
with Delay, SingleDosOK and Auxiliary Mode
28
SYSTEM:FIRSTDROP:OFF Deactivate the first drop function
29
SYSTEM:FIRSTDROP:ON Activate the first drop function
30
SYSTEM:FIRSTDROP:ADJUST:<starting value> Starts the first drop adjust
31
SYSTEM:FIXEDADJUST:OFF Deactivate the fixed adjust function
32
SYSTEM:FIXEDADJUST:ON Activate the fixed adjust function
33
SYSTEM:DOSOKDELAY:OFF Deactivate the DOSOK-Delay
34
SYSTEM:DOSOKDELAY:ON Activate the DOSOK-Delay
35
SYSTEM:SINGLEDOSOK:SETUP Set the Single-DOSOK signal to “Setup”
36
SYSTEM:SINGLEDOSOK:PULSE Set the Single-DOSOK signal to “Pulse”
37
SYSTEM:PASSWORD:<your password> Send the password for unlocking the keypad
Attachments
172
VTK-TR-BA-171e-1 - User Manual MDS 3080-V
RS-232C commands Functions
38
SYSTEM:PASSWORD:OFF Deactivate the password for unlocking the keypad
39
SYSTEM:PASSWORD:ON Activate the password for unlocking the keypad
40
SYSTEM:PASSWORD:SET:<your password> Set the password for unlocking the keypad
41
SYSTEM:AUXILIARYMODE:ON Activate the auxiliary mode
42
TEMP:? This command does not work in the MDS 3080-V
43
TEMP:<set point in °C> This command does not work in the MDS 3080-V
44
TRIGGER:SET:? Check the current pulse parameters
45
TRIGGER:SET:<RI>,<OT>,<FA>,<NL>,<NP>,<DL
>
Change the pulse parameters in the RAM
(“Rising”: 1/10 ms)
46
TRIGGER:SET:<RI>,<OT>,<FA>,<NL>,<NP>,<DL
>,1
Change the pulse parameters in the EEPROM
(“Rising”: 1/10 ms)
47
TRIGGER:ASET:? Check the pulse parameters in the RAM
48
TRIGGER:ASET:<RI>,<OT>,<FA>,<NL>,<NP>,<D
L>
Change the pulse parameters in the RAM
(“Rising”: 1/100 ms) (MDC returns “OK”)
49
TRIGGER:ASET:<RI>,<OT>,<FA>,<NL>,<NP>,<D
L>,1
Change the pulse parameters in the EEPROM
(“Rising”: 1/100 ms) (MDC returns “OK”)
50
STRIGGER:SET:<RI>,<OT>,<FA>,<NL>,<NP>,<D
L>
Change the pulse parameters in the RAM
(“Rising”: 1/10 ms) (MDC returns the saved parameters)
51
STRIGGER:SET:<RI>,<OT>,<FA>,<NL>,<NP>,<D
L>,1
Change the pulse parameters in the EEPROM
(“Rising”: 1/10 ms) (MDC returns the saved parameters)
52
STRIGGER:ASET:<RI>,<OT>,<FA>,<NL>,<NP>,<
DL>
Change the pulse parameters in the RAM
(“Rising”: 1/100 ms) (MDC returns the saved parameters)
53
STRIGGER:ASET:<RI>,<OT>,<FA>,<NL>,<NP>,<
DL>,1
Change the pulse parameters in the EEPROM
(“Rising”: 1/100 ms) (MDC returns the saved parameters)
54
VALVE:UP Open the valve
55
VALVE:DOWN Close the valve
56
VALVE:CHECK:OFF Deactivate the valve check at the start-up of the MDC
57
VALVE:CHECK:ON Activate the valve check at the start-up of the MDC
58
VALVE:CHECK:<value> Starts a valve check with the given Needle Lift
59
VALVE:OPEN Initiate a dispensing cycle with current parameters
(“Rising”: 1/10 ms) (MDC returns “OK”)
60
VALVE:OPEN:<RI>,<OT>,<FA>,<NL>,<NP>,<DL
>
Initiate a dispensing cycle with given parameters
(“Rising”: 1/10 ms) (MDC returns “OK”)
61
VALVE:OPENS<setup no.> Initiate a dispensing cycle with selected setup
(“Rising”: 1/10 ms) (MDC returns “OK”)
62
VALVE:AOPEN Initiate a dispensing cycle with current parameters
(“Rising”: 1/100 ms) (MDC returns “OK”)
63
VALVE:AOPEN:<RI>,<OT>,<FA>,<NL>,<NP>,<D
L>
Initiate a dispensing cycle with given parameters
(“Rising”: 1/100 ms) (MDC returns “OK”)
64
VALVE:AOPENS<setup no.> Initiate a dispensing cycle with selected setup
(“Rising”: 1/100 ms) ( MDC returns “OK”)
65
SVALVE:OPEN
Initiate a dispensing cycle with current parameters (“Rising”:
1/10 ms) (MDC returns the saved parameters)
Attachments
VTK-TR-BA-171e-1 - User Manual MDS 3080-V
173
RS-232C commands Functions
66
SVALVE:OPEN:<RI>,<OT>,<FA>,<NL>,<NP>,<D
L>
Initiate a dispensing cycle with given parameters (“Rising”:
1/10 ms) (MDC returns the saved parameters)
67
SVALVE:OPENS<setup no.> Initiate a dispensing cycle with selected setup
(“Rising”: 1/10 ms) (MDC returns the saved parameters)
68
SVALVE:AOPEN Initiate a dispensing cycle with current parameters (“Rising”:
1/100 ms) (MDC returns the saved parameters)
69
SVALVE:AOPEN:<RI>,<OT>,<FA>,<NL>,<NP>,<
DL>
Initiate a dispensing cycle with given parameters (“Rising”:
1/100 ms) (MDC returns the saved parameters)
70
SVALVE:AOPENS<setup no.> Initiate a dispensing cycle with selected setup
(“Rising”: 1/100 ms) (MDC returns the saved parameters)
71
WRITE:LCD:<text> Write an ASCII text on the display
72
SCENARIO:STATUS Check the status of scenarios and PLCstops
73
SCENARIO:OFF Deactivate the use of scenarios
74
SCENARIO:ON Activate the use of scenarios
75
SCENARIO:PLCSTOP:1:OFF Deactivate the PLC-Stop
76
SCENARIO:PLCSTOP:1:ON Activate the PLC-Stop
77
SCENARIO:SAVE:<scenario no.>:<values> Save the parameters for selected scenario
78
SCENARIO:READ:<scenario no.> Check the parameters of selected scenario
79
SETUP:SAVE:<setup
no.>:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>
Save parameters in a setup (“Rising”: 1/10 ms)
80
SETUP:ASAVE:<setup
no.>:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>
Save parameters in a setup (“Rising”: 1/100 ms)
81
SETUP:READ:<setup no.> Check the parameters of a setup (“Rising”: 1/10 ms)
82
SETUP:AREAD:<setup no.> Check the parameters of a setup (“Rising”: 1/100 ms)
83
BAUDRATE:0/1/2/3/4 Change the baud rate
84
GETTD Check the current time and date
85
MDC:RESTART Restart the MDC
