Communication Interfaces
VTK-TR-BA-171e-1 - User Manual MDS 3080-V
87
RS-232C commands Reaction time (ms)
For baud rate:
9600 bits/s 115200 bits/s
71. WRITE:LCD:<text>
60
40
72. SCENARIO:STATUS
680
340
73. SCENARIO:OFF
90
70
74. SCENARIO:ON
80
70
75. SCENARIO:PLCSTOP:1:OFF
100
90
76. SCENARIO:PLCSTOP:1:ON
100
80
77. SCENARIO:SAVE:<scenario no.>:<values>
100
90
78. SCENARIO:READ:<scenario no.>
680
340
79. SETUP:SAVE:<setup no.>:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>
90
80
80. SETUP:ASAVE:<setup no.>:<RI>,<OT>,<FA>,<NL>,<NP>,<DL>
90
70
81. SETUP:READ:<setup no.>
100
70
82. SETUP:AREAD:<setup no.>
400
340
83. BAUDRATE:0/1/2/3/4
60
40
84. GETTD
90
70
85. MDC:RESTART
210
190
Communication Interfaces
88
VTK-TR-BA-171e-1 - User Manual MDS 3080-V
8.1.2.2 Explanations
0
1 *ESR? ESR? = Event Status Register Query
Description:
This command shows the latest error codes created by the system, starting
with the latest event. At the most 50 error messages will be shown.
Each error messages also includes the valve ID (if known) and a time and
date stamp. If the RTC of the MDC is defect, the value will be given as
“00:00:00 2014-01-01”.
Example:
Input:
*ESR?
Result:
List of the (up to 50) latest error messages
Return:
8 199 VALVE ERROR 08FU04 09:16:38 2018-01-21
9 104 INCORR. VALVE 08FU04 09:16:21 2018-01-21
2 *ESR2? ESR2? = Event Status Register Query 2
Description:
This command shows the latest error codes created by the system, starting
with the latest event. There will be shown a max of 50 error messages.
Each error messages also includes the valve ID (if known) and a time and
date stamp. If the RTC of the MDC is defect, the value will be given as
“00:00:00 2014-01-01”. Additionally the parameters of setups 0 to 3 before
the error are listed.
Example:
Input:
*ESR2?
Result:
List of the (up to 50) latest error messages with parameters
Return:
20 199 VALVE ERROR 000000 09:16:38 2018-01-21
0, 0, 0, 0, 0, 0
0, 0, 0, 0, 0, 0
0, 0, 0, 0, 0, 0
0, 0, 0, 0, 0, 0
27 104 INCORR. VALVE 08FU04 09:16:21 2018-01-21
30, 5, 30, 80, 1, 20
50, 20, 20, 80, 1, 100
50, 20, 20, 80, 1, 100
50, 20, 20, 80, 1, 100
3 *IDN? IDN? = Identification Query
Description:
Device specific information, formatted as follows: type (hv, or lv), software
version. Important for contact with our Technical Support.
Example:
Input:
*IDN?
Result:
Micro Dispenser LV, 4071LU1-D
Return:
Micro Dispenser LV, 4071LU1-D
4 *OPC? OPC? = Operation Complete Query
Description:
Monitoring the last trigger impulses. After this, the counter is cleared to
zero.
Example:
Input:
*OPC?
Result:
Number of the last pulses. Clears the counter to zero.
Return:
6699
Communication Interfaces
VTK-TR-BA-171e-1 - User Manual MDS 3080-V
89
5 ADJUST:?
Description:
This command is used to verify the success of the adjust.
The result consists in one of the following options:
• Unknown state (Result: 0)
The system is not able to interpret the question and has to be switched
OFF and ON again. The adjust must be repeated. This event however is
an exception.
• The nozzle unit is too far down (Result: 1)
You have to screw the adjust screw in the direction “Close”. An adjust is
required (or must be repeated).
• The adjust was successful (Result: 2)
The position of the nozzle insert relatively to the tappet is OK.
• The nozzle unit is too far up (Result: 3)
You have to screw the adjust screw in the direction “Open”. The adjust
must be performed (or repeated).
Example:
Input:
ADJUST:?
Result:
The system informs about the current nozzle position.
Return:
2
The nozzle is correctly adjusted. Adjust was successful.
6 ADJUST:START
Description:
Sending this command causes the adjust to be executed at once. This
procedure checks on the position of the nozzle insert with respect to the
tappet. It is required during each initial start-up and after replacing the
nozzle unit.
For further information read paragraph 8.2.3, page 123.
Example:
Input:
ADJUST:START
Result:
The adjust is initiated.
Return:
Release NU Attention Fluid!!!!!
