3 Fitting the gantry
3.7 Final Work
Assembly Instructions / Montageanleitung SIPLACE SX1/SX2 V3 Reconfiguration Kit Twin VHF mit Portal
Reconfiguration Kit Twin VHF with Gantry 06/2020
125
Fig.56: Fitting the cover
► Fit the cover (1) over the gantry inter-
face.
3.7 Final Work
3.7.1 Empty Tape Duct Intermediate Plate
If tapes with high components are processed, you will need to remove the empty tape duct interme-
diate plate when upgrading a gantry with SIPLACE TwinHead or SIPLACE CPP and stationary
camera.
If you are only using component with tapes up to 12mm, keep the intermediate plate in the empty
tape duct.
Fig.57: Tape duct
1. Inlet slot for empty tapes
2. Outlet slot for the empty tapes above
the pneumatic tape cutter
3. Partition plate for tapes < 12 mm (can
be removed for tapes > 12 mm)
3 Fitting the gantry
3.7 Final Work
126 Assembly Instructions / Montageanleitung SIPLACE SX1/SX2 V3 Reconfiguration Kit Twin VHF mit Portal
Reconfiguration Kit Twin VHF with Gantry 06/2020
3.7.2 Stowing the Gantry Carrier and the Prepared Case
Stowing the gantry carrier in the transportation crate
► Use the gantry lift to move the gantry carrier into the transportation crate.
► Fix the gantry carrier into place in the transportation crate, with the four fastening screws.
► Release the gantry carrier from the gantry lift and move the gantry lift to one side.
► Place the foam cover for the placement head in the transportation crate.
► Close the front and top cover on the transportation crate.
Placing assembly parts in the "Prepared" case
Fig.58: Prepared case
You have removed the following parts which
you will need to dismantle the gantry later
on. Keep these parts in the "Prepared" case:
1. Black plastic foil for trailing cable
2. The long end position buffer.
3. Trailing cable holder with knurled head
screw
4. Two transportation locks for the place-
ment head
●
A green lever as transportation lock for
the gantry
3.7.3 Checking the Gantry Coding
Fig.59: DIP switch gantry encoding for gantry 1 and 2
1. DIP switch for gantry 1
2. DIP switch for gantry 2
► Check the DIP switch for the gantry
coding of the locations on the head in-
terface.
Switch Designation Gantry 1 Gantry 2
1 DC/DC OFF OFF
2 FAN OFF OFF
3 P1 OFF ON
4 P0 OFF OFF
3 Fitting the gantry
3.7 Final Work
Assembly Instructions / Montageanleitung SIPLACE SX1/SX2 V3 Reconfiguration Kit Twin VHF mit Portal
Reconfiguration Kit Twin VHF with Gantry 06/2020
127
3.7.4 Fitting the cover
Fig.60: Cover
► Fit the cover(1) on the boards.
► VHF heads also need edge protec-
tion(2)
to be present.
3.7.5 Note MGCU
Fig.61: MGCU supply cable [03068134-xx]
► Please check the connection of the
MGCU power cable with the connector
X1up (1)
to ensure a correct start-up of
the machine.
NOTICE
Dismantling a gantry
The connector X1up has to be disconnected from the MGCU, if the gantry is dismantled
later on.
See also
2 5.1.3 "Overview of MGCU (Rxxxx)" [}149]
