1 Introduction 1.4 Abbreviations Assembly Instructions / Montageanleitung SIPLACE SX1/SX2 V3 Reconfiguration Kit Twin VHF mit Portal Reconfiguration Kit Twin VHF with Gantry 06/2020 89 1.4 Abbreviations Abbreviations Des…

1 Introduction

1.3 Other instructions

88 Assembly Instructions / Montageanleitung SIPLACE SX1/SX2 V3 Reconfiguration Kit Twin VHF mit Portal

Reconfiguration Kit Twin VHF with Gantry 06/2020

1.3.3.2 Important measures to protect against static charging

► Most plastics can easily become charged and must therefore be kept away from at-risk com-

ponents.

► Always ensure that people, the workplace and packaging are safely earthed when handling

electrostatic sensitive components.

1.3.3.3 Handling ESD modules

As a general rule: Only touch electronic modules if you must carry out work on the modules. In that

case, make sure that you do not touch the pins or printed conductors when you pick up flat mod-

ules.

Only touch components if you are earthed by one of the following measures:

●

You are wearing an ESD wristband.

●

You are wearing ESD shoes.

●

You are wearing ESD shoe earthing strips on an ESD floor.

Immediately before you touch an electronic module, discharge your own body by touching a con-

ductive and earthed object (such as unpainted parts of a switch cabinet, a water pipe, etc.).

Do not allow modules with chargeable and highly insulating materials to touch one another, e.g.

plastic films, insulating table surfaces or items of clothing made from synthetic fibers.

Always place the modules on a conductive surface (table with an ESD coating, conductive ESD

foam, ESD bag or container).

Do not move the assemblies near to data view devices, monitors or television units. Keep a min-

imum distance of 10 cm to monitors.

1.3.3.4 Measurements and modifications to ESD modules

Only perform measurements on modules if one of the following conditions is fulfilled:

●

You are using an earthed measuring device (e.g. via PE conductors).

●

You are using a potential-free measuring device and discharge the measuring head before

the measurement (e.g.by touching an unpainted metal part of the controller casing).

► Always use an earthed soldering iron if you carry out any soldering work.

1.3.3.5 Dispatching ESD modules

► Always store modules and components in conductive packaging (e.g. metallized plastic bags

or metal sleeves) and dispatch them in conductive packaging

► If the packaging is not conductive, place the modules in a conductive envelope before pack-

aging. Use conductive expanded rubber, ESD bags, domestic aluminum foil or paper, for

example. NEVER use plastic bags or film.

► If the module has integral batteries, ensure that the conductive packaging does not touch or

short circuit the battery terminals and, if necessary, first cover the terminals with insulating

tape or material.

1.3.4 Release History

Document

SIPLACE SX1/SX2 V3

Reconfiguration kit Twin VHF with gantry

Assembly instructions

Edition Amendments

06/2020 Initial release

1 Introduction

1.4 Abbreviations

Assembly Instructions / Montageanleitung SIPLACE SX1/SX2 V3 Reconfiguration Kit Twin VHF mit Portal

Reconfiguration Kit Twin VHF with Gantry 06/2020

1.4 Abbreviations

Abbreviations Description

PA Placement area

CO Component

COT Changeover table

COT-i Changeover table insert

C&P Collect&Place

C&P12, CP12 Collect&Place head with 12 segments

C&P20, CP20 Collect&Place head with 20 segments

C&P6, CP6 Collect&Place head with 6 segments

CoD Capacity on Demand

CPP Collect&Pick&Place head

CPx Collective term for CPP, CP20, CP12 and/or CP6

ESD Electrostatic sensitive device

EMC Electromagnetic compatibility

FHE Fast Hardware Exchange

LBO Long Board Option

PCB Board

P&P Pick&Place

TH TwinHead
