Appendix G Coefficient of Thermal Expansion G-1.0 COEFFICIENT OF THERMAL EXPANSION Polymer systems expand with increasing temperature, dem- onstrating a glassy phase response with a coef f icient of thermal expansion (CT…
changing the materials of joint height, adding compli-
ant leads, or changing the materials of substrate or
component to decrease the ∆α.
• Perform DfM review of printed board layout- include
ease of inspection and rework of all solder joints, par-
ticularly those adjacent to ‘‘tall’’ components such as
connectors or in the PWA ‘‘valley’’ between such com-
ponents. Placing the non-termination portion of the
SMT component next to the TH component eases
inspection. Packages with heatsinks overhanging the
package edge lack inspectability and have a thermal
shadowing effect on neighboring parts during reflow; a
‘‘shadowed’’ part may require removal of the heat-
sinked part for rework.
July 1996 IPC-D-279
95
Appendix G
Coefficient of Thermal Expansion
G-1.0 COEFFICIENT OF THERMAL EXPANSION
Polymer systems expand with increasing temperature, dem-
onstrating a glassy phase response with a coefficient of
thermal expansion (CTE) or α
1
below T
g
, and a rubbery
phase response with a much higher α
2
, typically 3 times α
1
above T
g
. The transition from glassy phase to rubbery
phase is gradual, but for most polymer substrates may be
characterized by T
g
, the glass transition temperature. See
IPC-T-50.
Glass fiber reinforced substrates exhibit significantly differ-
ent CTE in the z (CTE(z), out of plane) axis compared to
the CTE in the x-y axes; for example, below its T
g
, Quartz/
Bismaleimide material with 35% resin by weight exhibits a
CTE(x,y) of 6 ppm/°C and a CTE(z) of 41. Woven glass
fiber reinforcement exhibits an additional difference
between x and y axes on the order of 1-5 ppm/°C; this dif-
ference may be significant where the CTE of a large SM
component package is to be matched to the CTE of the
substrate to enhance cyclic life of the solder attachments.
The CTE(z) is particularly significant in determining the
cyclic life of PTH and vias in SM PWAs because the aspect
ratio (ratio of substrate thickness to finished hole diameter)
is generally much larger than the corresponding aspect
ratio achieved in printed boards manufactured for through
hole technologies. Higher CTE(z) values result in higher
cyclic tensile stress in the barrel of the PTH or via during
temperature excursion during SM reflow, or SM compo-
nent removal/rework/repair as well as during printed board
fabrication, solder dipping, hot air leveling, or wave solder.
See IPC-TR-579 and IPC-SM-782.
The thermal cycle reliability, vibration robustness, and the
thermal management of high performance Surface Mount
(SM) products are heavily dependent upon the constraining
core such as Copper-Molybdenum-Copper (CMC),
Copper-Invar-Copper (CIC) and Molybdenum-Graphite-
Molybdenum (MGM) composite material systems.
The ratios of the various materials in those composite sys-
tems can be adjusted to tailor the effective CTE to the opti-
mum value. The tradeoffs include weight and cost. See
IPC-MC-324.
G-2.0 CONSTRAINING CORES
A constraining core is an internal supporting plane in a
packaging and interconnecting structure, used to alter the
coefficient of thermal expansion of printed boards.
Table G−1 Typical Values for Coefficients of
Thermal Expansion (ppm/°C)
Insulator/Substrate
Material/System
CTE
lower value upper
E glass 5.5
S Glass 2.6
Glass-Ceramic > 3.0
Silicon 2.6
Diamond 0.9
Aluminum Nitride 4.5
Silicon Nitride 3.7
Quartz, fused silica 0.5 0.6
Kevlar 49 -5
Beryllia 6
Cubic Boron Nitride
x-y 3.7
z 7.2
E Glass/Epoxy
x-y 14.2 17.3
x8090
E Glass/Polyimide
x-y 12 16
z6
E Glass/PTFE
x-y 24
z 260
Kevlar/Epoxy
x-y 5.1 7.1
z 5.1 7.1
Kevlar/Polyimide
x-y 3.4 6.7
z83
Quartz/Polyimide
x-y 5.0 8.0
z 68.4
Quartz/Bismaleimide
x-y, 35% Resin 6.2 6.3
z, 35% Resin 41
Alumina (90%) TF
Substrate
7.0
Alumina (Ceramic Chip
Carrier)
5.9 6.5 7.4
Epoxy (70% Silica) Plastic
Packaging
20 23
Mulite Co-Fired 4.2
IPC-D-279 July 1996
96
Insulator/Substrate
Material/System
CTE
lower value upper
Conductor Material/System
Alloy 42 4.4
Alluminum (40% Silicon) 13.5
Aluminum, T6061 23.6
Boron Aluminum (20%) 12.7
Copper, CDA 101 17.6
Copper/Invar/Copper
20/60/20 Thick
5.7 5.8
Copper/Molybdenum/
copper 20/60/20 Thick
7
Gold 14
Graphite/Aluminum 4 6
Invar 36 1.6
Invar 42 4.5
Kovar 5
Lead 29
Lead (95%) Tin Solder 28
Lead-Tin solder 60/40 23 25
Molybdenum 4.9
Ni-clad Molybdenum 5.2 6.0
Silver 19
Tungsten/Copper (90/10) 6.0 6.5
Tungsten 4
